Ninth part, about the liquid’s dielectric constant sometimes being irrelevant …
↓↓↓ Complete description, time index and links below ↓↓↓
In the eigth video we’ve successfully tested our setup with a reference sensor by measuring the levels of two liquids with vastly different dielectric constants – water and saline (link below). However, at the end I told you there was an oddity.
First we’ll have a look at that oddity and another. Then I attempt to explain them and prove myself wrong. Desperate I measure methanol too before coming up with the correct answer. Finally we verify everything by measuring vegetable oil.
00:00 Intro – oddities in the previous videos’ measurements
00:57 Oddities – dielectric constant irrelevant and thin film effect
03:45 Theory A – incomplete & wrong: only short field lines matter
08:10 Ethanol – measuring another liquid yields identical values
11:13 Theory B – complete & correct: liquid behaving as conductor
18:50 Rapeseed oil – isolating, low dielectric constant liquid
26:37 New physics – unfortunately not, it’s known in the industry
29:38 Wrap-up – there will be one more video, bye
