Hi, everyone. I'm Evangeline right here at etrailer. Today, we're taking a look at the RV Designer Speedwire Dual Outlet. This is going to be a 120-volt outlet that you can either add to your RV or use to replace an old one. With this being a speedwire outlet, it has a slightly different method of connecting the wires to the outlet that creates a little bit more of a firmer grip on the wire. So if you stick around to the end of this video, I'll also show you how to get that set up.
RV outlets will look a little different compared to your residential outlets if you've ever had to install those. On the outside, they look the same. So you can see a couple different options and different colors available here at etrailer. On the inside, they're a little different. These are designed to be self-contained boxes that can handle the extra vibration of being on a rope.
So compared to a house where it's not going to be jumping around and vibrating around, therefore you can get away with using a separate box and then installing an outlet in there, this one has everything contained. Having that functionality of being self-contained so that your wires will not make any contact with any metal outside of the outlet, plus being able to have that extra grip on the wire so that vibration won't move the wires out of placement, is almost worth the extra hassle that goes into replacing these outlets. Now, the speedwire version is available only in white here at etrailer, but if you want a dual outlet, but maybe in a different color, we have RV Designer dual outlet options, very similar in design, slightly different in how you push the wires in. So I think it's totally okay to go that route if you want, let's say, a brown or a black version instead. If you are replacing, then that process is going to be super simple because this will fit into pretty much any regular dual outlet spot.
If you are upgrading from maybe a smaller outlet or adding an outlet spot where there was not one before, well, check out the dimensions here on our site. That will help you out with that cut-out process. As for the wiring process, we're not going to go into that into this video. Something I recommend doing is checking out one of our local installers to you since that will be a little bit of a more involved process. But if you're just curious about the replacement process, well, stick around.
All you're going to need is a flathead screwdriver for prying off the faceplate, a Phillips head screwdriver for tightening down the toggle that is already included with your outlets, and make sure to turn off your RV and trailer. That involves unplugging from shore power, turning off your inverter, flipping at your breakers, everything to make sure there's no power going through as you replace your outlet. To start installing or replacing your new outlet, if you have an old outlet, you're first going to have to remove it. That process will be different for different people. What this outlet here needed was I needed a flathead screwdriver. I just pop off that plate and that actually removes from the outlet. And then from there I was able to loosen the top corner bolts, and then that has a toggle in the back and I was able to remove it. Now, here, taking a look at this old outlet, the older toggle is actually off and I already took off the backplate. We can see our wires over here, and something a lot of people like to do is also just double-check and verify the orientation of the plate so that if they replace it's the same as before. I personally am a ground hole facing up person, but if you want to match the old socket, this is a way to make sure you do. Now, here, I'm just gonna lift the wires away. They are pretty jammed in there, so I am going to just grab a screwdriver just to help pry them up and out. See how that's working well. Again, this is only possible because all the power is off. Now, we have our new outlet, and just to double-check, again, checking the orientation and also on the outlet it says white wire, black wire, and then in the center it'll say green wire. So matching that up with our wiring here, this one's pretty straightforward since it matches exactly what the other one did too. And I'm going to start getting these in position to jam down. This is probably the hardest part of the whole process. It requires a lot of muscle to get this into place. Yes, it's technic
