I was trying to 3D print a replacement needle for my small knitting machine. I used the Revopoint POP scanner. I ran into a problem with it not being able to scan small parts. Support told me that part should be at least 50x50x50mm. I got around the problem by putting the small part on top of a larger one. Unfortunately this requires you to edit out the extra scan data. With such a small part, the three different scan views were pretty ratty. I managed to align them. I used a set of calipers to go over ever dimension I could and put the "correct" value in. I got a pretty good CAD model. My SLA 3D printer did a nice job with the print. Even my 3D EDM printer was able to print it (it was pretty ugly), but it still worked!
I put the 3D model of the knitting needle at:
prusaprinters.org/prints/136553-knitting-machine-needle-replacement
thingiverse.com/thing:5254168
Here are the things I used:
* Revopoint POP 3D Scanner ( amzn.to/35a6E1U )
* 22 needle knitting machine ( amzn.to/3JJDmGx )
* Elegoo Mars 2 Pro SLA Printer ( amzn.to/34NI1IL )
* Elegoo Mercury Plus Wash and Curing Machine ( amzn.to/34NI1IL )
* Isopropyl Alcohol 99%, One Gallon ( amzn.to/3s3HR8X )
* Overature Grass Green PETG filament ( amzn.to/3IMLghX )
FTC Disclaimer: We may earn commissions for purchases made through the links below. As Amazon Associates we earn from qualifying purchases.
