Baffled Drop Shaft Comparison | FLOW-3D HYDRO @flow3d

Uploaded May 2024 | Updated September 2026, 1 week ago

This video, courtesy of IIHR, Wade Trim, and Northeast Ohio Regional Sewer District, shows a comparison of a FLOW-3D HYDRO CFD model of a baffled drop draft structure under wet weather conditions with a physical laboratory model. Learn how FLOW-3D HYDRO is used to model drop shafts and other stormwater infrastructure at flow3d.com/products/flow-3d-hydro/conveyance-infrastructure/.

Baffled Drop Shaft Comparison | FLOW-3D HYDRO
