Circular Fishway Design | FLOW-3D HYDRO @flow3d

Uploaded July 2026 | Updated September 2026, 1 week ago

FLOW-3D HYDRO is a fully 3D CFD simulation tool that allows for highly accurate and detailed prediction of the hydraulic conditions critical for successful fish passage design. In this circular fishway pool concept, the user can simulate the full 3D flow field for high-resolution velocity, depth, and turbulence characteristics. FLOW-3D HYDRO improves on traditional 1D and 2D approaches, allowing higher accuracy and flexibility in analyzing project-based designs. FLOW-3D HYDRO users can model more complex flow features and evaluate hydraulic conditions encountered by the fish, providing valuable insights for various stakeholders in the fish passage industry. Learn more at flow3d.com/fish-passage-solutions
