Homebrew Four Pole 9 MHz Filter installed temporarily in a radio @N6QW
Homebrew Four Pole 9 MHz Filter installed temporarily in a radio  @N6QW
Uploaded February 2022 | Updated November 2026, 10 hours ago
This filter was initially built using one of the Premier filter design programs which resulted in a really crappy filter, I did a J & P (jerk and pull) of those components and substituted five 47PF SMD caps and the matching transformers are 9:1. Yes, a sweep with a Nano VNA shows a FLAT response,

This filter is headed for a Peashooter variant transceiver. It was temporarily jury rigged into a working transceiver and that is what you hear. The VNA Saver programs spits out the USB/LSB BFO frequencies.
