Measuring temperature with a PTC thermistor and an ADC …
↓↓↓ Complete description, time index and links below ↓↓↓
Last time we build our electromagnetic compliant (EMC) power supply, based on a switch mode regulator (link below). We still have an ADC input left, so let’s measure the temperature, because everything will be in an unventilated case.
First we look at the general options for temperature measurement, settling on a thermistor. After discussing NTC and PTC thermistors, we build our circuit around a TMP61 PTC and an ADC input. The result is good enough for our purposes.
00:00 Intro – temperature monitoring should things get hot
00:38 Options – digital sensor, thermocouple, thermistor
02:36 Thermistors – NTC vs linear, silicon based PTC
06:41 Texas Instruments TMP61 – 10kΩ ± 1 linear PTC
09:51 Circuit – voltage divider with PTC plus buffer capacitor
17:03 Breadboard – added a resistor, a PTC and a capacitor
17:55 Real values – of used resistor and PTC thermistor
18:53 Math – for PTC thermistors and voltage divider
22:14 Code – nothing we’ve not done already
26:36 Test – 5°C noise, error +3.5°C, good enough
28:48 Wrap-up – next we do some housekeeping, bye
