Uploaded March 2022 | Updated September 2026, 1 week ago
I also made a slow motion version of this video where it is easier to see what my fingers are actually doing on the controls, you can find it here:
youtube.com/watch?v=OqQoiA8XBsI
But for those that prefer to get the real-time version with no slowmo nor music, well, I have you covered as well ;)
This was my first 'transmitter split-screen' video for the F-22 Raptor!
Hopefully you can take advantage of it to analyze the inputs that I make to perform these aerobatic maneuvers, and you may be able to import some of it into your own flying skills. ;)
Hope you find it helpful, or entertaining at the very least!
Shameless plug: if you want to contribute to my work, please consider having a look at some of my merch! ;)
airguardian.creator-spring.com
These were flights 92nd to 95th on 'Scarlett'.
Pilot: Airguardian
Ground video: Luis Ibáñez
Airfield: Club Els Cards
SPECS (Reflecting my setup):
Freewing F-22 Raptor Ultra Performance 8S 90mm EDF Jet - PNP
12-Blade EDF power system (installed)
4075-1390Kv inrunner brushless motor (installed)
150A ESC with EC5 connector (installed)
Electronic retractable landing gear (installed)
Servos, LED Lights (installed)
Model Scale: 1/13th
Wingspan: 1060mm
Length: 1500mm
Empty Weight: Around 3100g (w/o battery)
TOW: Around 3900g
CG: +160mm from the leading edge of the wing at the root
Material: EPO
Motor: Stock 8S 4075-1390Kv Inrunner
ESC: Stock Freewing (Hobbywing) 150A, HV
EDF: Stock Freewing 90mm 12-Blade
Servos: (All stock)
- 2x 9g Digital hybrid gear
- 2x 17g Digital metal gear
- 6x 23g Digital metal gear
Landing Gear: Electronic retractable with all metal shock absorbing struts
Receiver: FrSky X8R, using 12 channels so far (user choice)
Gyro: Hobby Eagle A3S3 (added as a mod)
Separate UBEC: TGY 8-15A (added as a mod)
Receiver battery: Rhino 2S 500 and 610mAh (added as a mod)
Main battery packs: (All weighing around 800g combined)
- HRB 2x 4S 4200mAh 50C
- Turnigy Panther 2x 4S 3000mAh 75C
- Turnigy Nanotech 2x 4S 3300mAh 70C
Mind that although most of the jet is stock, I performed several modifications. Removed the infamous Blue Box and wing ribbon wires, passed individual leads to wing servos, mixed them all separately, removed pilot figure and nose gear light, installed a HE A3S3 gyro (which required physical servo reversing one stabilator servo, inverting motor and pot wires), added a green LED to make a fake HUD reflection effect, airbrushed the canopy to make it look more golden, like the full-scale one. Need to pick the sun at the right angle to show up though!
More details on my setup coming soon!
