Hello and welcome to 80/20’s product highlight series. Today we are going to take a look at door glides. These door glides allow two profiles to slide together with ease, perfect for bi-fold doors. They are easy to install, available in both fractional and metric, and compatible across a wide range of profile series.

Now when it comes to using the door glide, machining will need to be done to one of your bars, with one end tap on one end. More information on 80/20’s machining services can be found in the 80/20 product catalog.

Now when it comes to installing it, you’ll take the door glide, and simply thread it into the end tap. From there you’ll get it down flush with the end of the profile. Take your mating profile, and slide it right in. From there, you have a functioning door glide with nice smooth movement.

Now hopefully you found this segment on door glides helpful. For more information, visit 8020.net, and make sure to subscribe to future 80/20 videos. And as always, make it a great day.
