Uploaded March 2022 | Updated September 2026, 1 week ago
Experience our latest applications here: keysight.com/find/vnasoftware
Find the right Network Vector Analyzer for you: keysight.com/find/na
0:00 Introduction to Keysight's software application
0:29 Hardware setup required for compliance testing
0:42 Software setup
1:09 Walkthrough of the software
1:29 Frequency domain measurements for USB type-C cables and how to read them
1:57 How to debug
2:29 Test MOI (Method of Implementation)
3:20 Keysight's available testing hardware
Keysight Enhanced TDR is a Network analyzer software application that provides one-box solution to perform high-speed interconnect analysis, including impedance, S-parameters and eye diagrams.
This demonstration video shows how Keysight Enhanced TDR helps to simplify the test process for USB Type-C cables compliance testing to accelerate your design, debug, characterization to compliance in one complete solution.
