Gas porosity in steel castings can be analyzed using simulations of mold filling with entrained air mass or volume. Shown here is a simulation of entrained air volume with plots quantifying mass and volume of entrained air in metal vs. time. The particles represent any collapsed bubbles that are likely to show gas porosity within the casting. Learn more about FLOW-3D CAST's sand casting simulation workspace: flow3d.com/products/flow-3d-cast/sand-casting-workspace/.
