Uploaded December 2025 | Updated November 2026, 4 days ago
Meshtastic is an open-source, decentralized communication network built on LoRa technology. In my previous video, I set up two Meshtastic nodes using the XIAO nRF52840 and Wio-SX1262 Kit. In the second video, I upgraded them by enabling I2C support and adding the Telemetry module to report temperature and barometric pressure from a BMP280 sensor. To enable I2C, I recompiled the Meshtastic firmware for the XIAO nRF52840 and Wio-SX1262 Kit from source. This also made it possible to connect a mini OLED display. I used a yellow-blue 0.96โณ SSD1306 IยฒC OLED display that operates at 3.3 V, wiring SDA to D6 and SCL to D7 on the XIAO nRF52840, instead of the default hardware IยฒC pins, as defined in the Meshtastic firmware configuration.
To compile the Meshtastic firmware from source with I2C support for the XIAO nRF52840 and Wio-SX1262 Kit have a look at my other related video:
youtu.be/zhS_2MZbjzM?si=Mg-hwTyip0chQt7W
๐ SSD1306 Wiring for Meshtastic Firmware on XIAO nRF52840 and Wio-SX1262
===
GND to GND of XIAO nRF52840
VCC to 3.3V of XIAO nRF52840
SDA to D6 of XIAO nRF52840
SCL to D7 of XIAO nRF52840
NOTE: this wiring is specific for the Meshtastic firmware built using the configuration seeed_xiao_nrf52840_kit_i2c
๐ฅ Related Videos
===
Getting Started with Meshtastic: XIAO nRF52840 & Wio-SX1262 Setup and First Test
youtu.be/lOhg--tFEUg?si=8g-44pyJYJE6kJ13
Custom Meshtastic Firmware: Add I2C and BMP280 Sensor Telemetry on XIAO nRF52840 & Wio-SX1262
youtu.be/zhS_2MZbjzM?si=Mg-hwTyip0chQt7W
๐ Useful Links
===
github.com/meshtastic/firmware
Meshtastic Firmware Build Configurations for XIAO nRF52840 & Wio-SX1262 Kit
github.com/meshtastic/firmware/blob/develop/variants/nrf52840/seeed_xiao_nrf52840_kit/platformio.ini
Meshtastic Firmware Pin Configurations for XIAO nRF52840 & Wio-SX1262 Kit
github.com/meshtastic/firmware/blob/develop/variants/nrf52840/seeed_xiao_nrf52840_kit/variant.h
BMP280 in Meshtastic Firmware
github.com/meshtastic/firmware/blob/develop/src/modules/Telemetry/Sensor/BMP280Sensor.cpp
XIAO nRF52840 & Wio-SX1262 Kit
wiki.seeedstudio.com/xiao_nrf52840&_wio_SX1262_kit_for_meshtastic
XIAO nRF52840 & Wio-SX1262 Kit for Meshtastic
seeedstudio.com/XIAO-nRF52840-Wio-SX1262-Kit-for-Meshtastic-p-6400.html
Getting Started with the Meshtastic Kit: XIAO nRF52840 & Wio-SX1262
anavi.org/article/334
Attaching a Mini I2C SSD1306 OLED Display to Meshtastic Kit with XIAO nRF52840 and Wio-SX1262
anavi.org/article/341
๐ Chapters
===
0:00 Intro
0:46 Enable I2C
3:34 Wiring
4:54 Config
7:28 Demo
9:16 Advantages
9:31 Disadvantages
10:26 Conclusions
