Diode Lasers - Under the hood 02 @SarbarMultimedia

Uploaded March 2024 | Updated September 2026, 1 week ago

There is so much to be learnt from the way that a CO2 laser beam behaves. The long wavelength beam interacts with clear acrylic in such a manner that it reveals all of its secrets. The biggest secret being that it is not POWER but INTENISTY that is responsible for damageing materials. There is no way to see this effect with fiber or diode lasers because there are no equally suitable materials available that respond to the short wavelength light. The open nature of a CO2 beam system allows investigation of the beam INTENSITY profile both before and afetr it passes through a lens. The results are suprising.
