TangerineTiger 11 Making Dots How hard can it be @SarbarMultimedia

Uploaded October 2020 | Updated September 2026, 2 weeks ago

Dots are the basis of dithered photo engraving. The simple rule is 1 dot = 1 pixel. This machine has pulses at its operating heart so therefore must be fast responding, Fast response should give the capability of producing crisp clean dots.......that's what I have always imagined of RF lasers, It turns out the opposite is true . That fast response prevents crisp ROUND dots.
