Photo engraving 2 @SarbarMultimedia

Uploaded April 2023 | Updated September 2026, 1 week ago

Part 1 was all about the therory of digital graphics and how resolution and image size are intimately entwined. Dithered images are based on pixels but there are limtations on what size pixels can be reproduced with hobby laser macines. This part 2 is all about creating small dots with a laser machne to emulate pixels. It's not as simple as most users think. There are many factors that will ultimately affect the size of a burnt dot. These include the material, the lens type and its orientation, the intensity profile within a laser beam and the laser beam control system.

This session demonstrates that if you can create dots to match a pixel size, then you can do photo replication with no image "interference" or "preperation".

The little 254ppi bitmap test pattern used in this video can be downloaded with this link
https://workdrive.zohopublic.eu/external/b8320305cb514fb43bc42afdbba89c8e1518a86607a6084b005d0cf5057ea15c/download
