80/20 Ideabuilder®: Updated UI Overview (ver. 2.0.0) @8020llc

Uploaded April 2025 | Updated September 2026, 1 week ago

IdeaBuilder: bit.ly/3WtfNJS
80/20 Website: bit.ly/3peM7n3
Need help? Contact us directly: IdeaBuilder@8020inc.com

Ideabuilder® is a web-based design software that allows you to design with the 80/20 catalog right in your browser. Export your project as an XML, save exploded drawing files, and generate a bill of materials for price estimates. Once you've got your bill of materials and drawings, reach out to your local 80/20 distributor to get started. bit.ly/3SY94Y7

In this video, we review the overall user interface. This is version 2.0.0, and new functionality has been added to the software for some products from 80/20's steel pipe and joint system.

*Due to constant updates, the look and functions available in the User Interface may vary from the time of this video and a new one will be released when available.
