Tishitu explains
This is a simple water heater by clips and Plates
you can heat water upto 20 Ltrs in 15 minutes with plates one
and with clips one One Ltr. in 6.5 Minutes. Concept is quiet simple in between plates there is water with minerals or we can say TDS (Total Dissolved Solids) in water make water ionize and behavior of Alternating Current vibrates those minerals and conduct electricity make water Hot.
Here we require some components are
1. Metal Stainless Sheets
2. 10 Amp for Wire Power source
3. Wire cutter Stripper
4. Wire tie
5. Metal Clips
6. Plastic Rod 2-3 Inch
7. Cloths holding Metal Clips
8. Bucket :)
