Name: Leslie Dan: Lifting the Steel Beam with the Crane @tboake3000
Uploaded: 2013-02-13T01:29:31-0400
Duration: 8 min 17 s
Description: Construction of the Leslie Dan School of Pharmacy at the University of Toronto, designed by Foster+Partners. This video shows the initial lifting of the steel beam by the crane. Notice the triangulation of the lifting points to the crane hook in order to keep the beam balanced.

Steel Butt Joint in Double Shear @tboake3000

Uploaded September 2020 | Updated September 2026, 1 week ago

This animation illustrates a steel plate butt joint with plates on either side of the tension connection to create a condition of double shear in the bolts. Content created by Vincent Hui for a CISC Research Project.
