Here's the specs on what you need to build a custom stove burner riser so you can use a standard burner or standard regulated burner on a one-pint stove like the Optimus 00. You'll probably need to get a machinist to custom cut a tap for the non-standard burner thread. The best fit is a 37/64" major diameter thread with a 34 threads-per-inch pattern. A 14.5mm major diameter with a 0.75 pitch metric thread is the next best fit.
The M13x1.00 tank thread is a tight fit, so you'll need to manipulate the custom order metric tap to cut the thread slightly deeper. Make sure to use a bottoming tap to cut threads all the way to the bottom of the riser socket and have a completely flat bottom to the tank connection.
You can get a lot of specialty taps (including the M13 x 1.00 tap for the tank connection) and to do other stove work at Victor Machinery:
victornet.com
Small lengths of 3/4" brass hex stock are available through Online Metals:
onlinemetals.com
Full size spirit pans are available here:
stores.ebay.com/A-H-Packstoves-Supplies-and-Parts
or, here:
stores.ebay.com/PRIMUS-STOVE-and-TILLEY-LAMPS/PRIMUS-STOVE-PARTS-UK-
"Free" background tunes courtesy of YouTubes Audio Library. Artist: "Jingle Punks", tune: "In the Land of Rhinoplasty".
