Oil Water Separator | FLOW-3D HYDRO @flow3d

Uploaded July 2025 | Updated September 2026, 1 week ago

FLOW-3D HYDRO is an ideal tool to simulate multiphase flows in the field of produced water and optimize design to achieve the best performance. This simulation shows a baffled oil-water separator. As we can see, the heavier water phase stays at the bottom (dark blue color), while the lighter oil phase rises to the top (light grey color), and eventually flows over a weir to be separated from the water phase. Learn more at flow3d.com/hydro
