Magedok T116D 1080 x 1920 10 point touch screen review @TheBreadboardca

Uploaded November 2018 | Updated September 2026, 3 weeks ago

This video is a review / test drive of the Magedok T116D portable display, features include

11.6" 1080 x 1920 resolution
9x16 aspect ratio
10 point capacitive Touch
built in speakers
interface with a USB 3.1 Gen 2 with a single cable including power
or via HDMI, Power and Touch via USB

Tested with Raspberry PI, PC, Canon HD G30 video Camera
Works well with MS Surface V3 Active Pens.

I would like to thank Magedok for sending me this review unit

Links to Magedok here for more products and direct pricing
goo.gl/2oB6tF

Amazon
DE：amazon.de/dp/B07F8QJG5N
UK：amazon.co.uk/dp/B07F8QJG5N
CA: amzn.to/2BpLxqV
NOTE:- As an Amazon Associate I earn from qualifying purchases but there is no additional cost to you.

The model I reviewed did not include VESA mounting holes but now the model does, also there is a metal backed version the T116C
