Uploaded March 2026 | Updated September 2026, 3 weeks ago
This class is a great lesson in in-cylinder pressure analysis and why pressure transducer testing can take you to the right answer when other tests point you in the wrong direction.
In this case, the vehicle felt like it had a plugged exhaust. Even the symptoms and some of the early test results pushed us that way. But the in-cylinder pressure waveform told a different story. By looking at exhaust-stroke pressure, intake vacuum, running compression, and valve event timing, we were able to prove this was not a restricted exhaust and move toward the real problem.
Watch Part 1 here:
youtu.be/8q1OaCYe8bY
This is also a strong reminder that cam/crank correlation alone does not always tell the full story. The known-good comparison was spot on, yet the in-cylinder waveform showed clear evidence of a timing-related issue.
If you want to get better at reading pressure transducer waveforms, measuring valve events, and using running compression as a diagnostic tool, this class is packed with value.
🔧 Looking for deeper training?
Join ScannerDanner Premium for full courses, case studies, and foundational diagnostics training:
scannerdanner.com/join-scannerdanner-premium.html
On ScannerDanner Premium, you’ll get:
• In-depth classroom lectures straight from my book
• Real case studies with known-good and failed test results
• Training focused on process, not guesswork
• Electrical, electronics, and drivability diagnostics
• Access to hundreds of hours of premium content
📘 Want to learn more about diagnostics?
Check out my book, Engine Performance Diagnostics, plus tool links here:
https://linktr.ee/scannerdanner
00:00 In-cylinder pressure proves it’s not a restricted exhaust
04:09 Running vs. cranking compression reveals a major breathing problem
07:52 Exhaust valve opening and intake valve closing both point to late cam timing
13:11 Spark timing checks show the whole event is shifted
18:47 Cam/crank correlation still looks normal because of a shifted crank keyway theory
23:26 Recall research and crank gear design support the damaged-keyway conclusion
29:43 Hard brake pedal was caused by low engine vacuum, not a bad brake booster
32:52 Final teardown begins to confirm the diagnosis
#ScannerDanner #InCylinderPressure #PressureTransducer #RunningCompression #EngineTiming #AutomotiveDiagnostics #OscilloscopeDiagnostics #DrivabilityDiagnosis
