This is a guide on replacing a screen on a Lenovo ThinkPad T460 laptop

For the replacement process we will need:
- a plastic pick
- a Phillips screwdriver
- and an Exacto knife

To begin turn the laptop off and disconnect the power cord.
Remove the battery from the bottom.

This laptop has two bezels. Start removing the first floppy bezel.
Insert a plastic pick between the bezel and the LCD.
Move the pick around the perimeter. Insert the plastic pick between the
bezel and the back cover. Move it along the edges. Use Exacto knife to cut
strands of glue. Put the bezel aside.

Now we can remove the second inner bezel. Use Exacto knife to remove glue
covering the Phillips screws in the corners. Remove 4 screws.
Use plastic pick to separate the bezel from the back cover. Put the
bezel aside.

Now we have access to the LCD. Place the screen on the keyboard.
Using plastic pick open the connector’s bracket. Using both hands disconnect the video
cable. Discard the old screen.

Place the new screen on the keyboard. And using both hands gently r econnect the video cable and
close the connector’s bracket.

CAUTION! It is very important not to force any connectors. Also
make sure not to twist or slant the connector when plugging it in.

Lift the screen up and lean it against the back cover. Test the new screen.
The screen is working and we can finish the installation process.

Replace the inner bezel. Go around the perimeter fitting bezel in place.
Replace four Phillips screws in the corners.

Now we can replace the outer floppy bezel. It still has a glue sufficient
to hold it in place. Go around the perimeter applying some pressure.
Make sure that the bezel is in place at the bottom and near the hinge covers.

Replace the battery, reconnect the power cord, turn the laptop on
and we are done!
