How it works
(1) Oil flow path
The oil flows through the tube bundle where, by thermal conduction, it releases its calories to the fuel tubes. The temperature range at the oil outlet is -40 deg.F (-40 deg.C) to 367 deg.F (186 deg.C).
(2)Fuel flow path.
- The fuel flows inside the fuel tubes and takes away the heat released by the oil.
If the differential pressure between the inlet and the outlet of the matrix is more than 14.5 psi (100 kPa):
- the pressure relief valve opens,
- the fuel flow bypasses the matrix and returns to the fuel tank via the FRV.
And since you know how this system works, let me show you how to replace one of the lead
**********video is just for information purposes always stick to the latest maintenance manual. *********
if you want support me click here:
youtube.com/channel/UCWiyEWY890-yYO636uUUUiA/join
My Flashlights Fenix E06R Pro:
youtu.be/Vuoz6d96PzI
fenixlight.com/product/e06r-prp
My Headlight Fenix HM75R
youtu.be/YDFdgKQ_ayg
fenixlighting.com/products/fenix-hm75r-rechargeable-headlamp-plus-power-bank?variant=42909791846454
Where you can find me:
Instagram: instagram.com/zeto.r
tiktok: tiktok.com/@zeto.r
Patreon: patreon.com/Zetomaintenance?utm_campaign=creatorshare_creator
Linkedin linkedin.com/in/tom%C3%A1%C5%A1-zeman-1861a094
———-Video content———————
00:00 - Intro
00:20 - Draining of the IDG
01:42 - Draining of the oil cooler
02:35 - disconnection of oil lines
03:35 - Disconnection of the fuel lines and explanation
06:50 - removal of the oil cooler
08:56 - what is inside and what is the reason for replacement
11:14 - installation of the oil cooler
13:42 - connection of the fuel lines
15:53 - connection of the oil lines
17:41 - engine run
19:48 - leak check with reset of IDG disconnecting system
20:35 - second engine run
21:57 - outro
