Uploaded May 2025 | Updated September 2026, 1 week ago
Proximity sensors are vital part for aircraft systems, specialy for indication, because proxi sensors are resposnible for telling aircraft systems position of components.
Description:
The proximity sensor is an electronic position indicator. The main components of the sensor are a sensor body, a sensor coil and an electrical connector. The sensor has a related target.
The sensor body contains the sensor coil. The coil is connected to the electrical connector.
Each proximity detection circuit contains:
- a proximity sensor
- a sensor target
- a channel of a proximity-sensor electronics card.
The proximity-sensor electronics-card has 14 channels and is located in the LGCIU.
Operation
The proximity sensor continuously transmits an electrical signal to the proximity-sensor electronics-card. As the target moves into or out of the proximity-sensor's actuation area it causes a change in the proximity sensor's electrical property. The electrical signal to the proximity sensor electronics card also changes. The proximity-sensor electronics-card converts these electrical signal changes into user status signals. The LGCIU control logic modules use these user status signals to control the extension and retraction of the L/G.
In today's video we will take look how to replace it.
*********video is just for information purposes always stick to the latest maintenance manual.*********
if you want support me click here: youtube.com/channel/UCWiyEWY890-yYO636uUUUiA/join
Where you can find me: Instagram: instagram.com/zeto.r
tiktok: tiktok.com/@zeto.r
Patreon: patreon.com/Zetomaintenance?utm_campaign=creatorshare_creator
Linkedin linkedin.com/in/tom%C3%A1%C5%A1-zeman-1861a094
———-Video content———————
00:00 - Intro
00:24 - what is proximity sensor good for
02:49 - Removal of the sensor
04:55 - Installation of the sensor
06:30 - how sensor work
06:36 - Continuation in installation
10:47 - Test
11:38 - sealing and close up
13:00 - outro
#airbus #airbus320 #a320 #aircraft #aircraftmaintenance #howto #aircrafttechnician #proximityswitch #antiskid #mlg #landinggear #aircraftengineer #aircrafttechnician#aircrafttechnician #wheelreplacement #aviationgeeks #aviationgeeksociety #proximitysensor #zeto.r #breakdown #components #aircraft #aircraftmaintenace #wefixyoufly #learningeveryday #creatingjourneystronger #austrianairlines
