Here's What Happens When You FLUSH A TRANSMISSION With OVER 245,000 MILES!! Transmission Flush On A Toyota 4Runner With OVER 245,000 MILES!!
*** I am an Amazon associate. I make a commission based on sales through my Amazon associate links.***
Valvoline MaxLife ATF: amzn.to/3NZUKyz
Vinyl Tubing 1/2" ID 5/8" OD: amzn.to/4mebrCP
Oil Drain Pan: amzn.to/4dxjJn7
1roadgarage.com
In this video I perform a passive transmission flush on my 2005 Toyota 4Runner (4th Gen 4Runner) Limited with the 4.7L V8. This vehicle is a bit different than others due to having, from the factory, two transmission fluid coolers. The one, that most others have, is located on the side of the radiator. The second cooler is an external type located just in front of the air conditioning condenser.
Because of this extra external cooler it was a bit difficult trying to figure out which line, coming out of the transmission, was the supply. Through a bit of trial and error I was able to confirm the bottom hard line coming out of the transmission was indeed the supply. With this knowledge I was able to trace the lines to the last possible point in the transmission cooling system just before it returned back to the transmission.
It was at this point, the hard line coming out of the top of the external cooler, that I chose to disconnect the factory return line and connect my clear vinyl line to drain into my bucket. This location worked perfectly. I was able to flush the old transmission fluid in 2 quart increments with no issues. After each 2 quart pump out, I would then shut the engine down and refill with 2 quarts of new fluid. This method I consider 'passive' because it is simply using the transmission's own pump to pump out its own fluid.
***This channel is for entertainment purposes only! Do not do what I do. Do not take my advice. I am not a professional. The methods I use may be completely wrong and/or dangerous. Please seek professional help with anything and everything and do your own due diligence (research). Working on cars is extremely dangerous. I am not responsible for any loss of life or limb or property. DO YOUR OWN RESEARCH. THIS CHANNEL IS FOR ENTERTAINMENT PURPOSES ONLY!***
FTC Disclaimer: I am an Amazon associate. As such, I earn a percentage of sales made through Amazon associate links found in the description of my videos and on my website and other places.
00:00 Introduction
00:58 Don't Flush Transmission Fluid
01:56 Finding The Supply Line
04:11 Connect The Drain And Fill
05:19 The Master Plan
05:40 Start Transmission Flush
10:01 Fluid Level Check
10:58 Transmission Test
12:52 Conclusion
