I repaired this twice already. First time it came in with one channel blown and stuck in Protect. I fixed it, had it working on the bench, but when the customer tried it the same channel went into protect again with no signal or speakers attached. It came back in with blown output transistors, Mosfet, Triac, and a scorched part of the PCB. So I fixed it again and found another problem. Will it behave itself now?
Part one is here : youtube.com/watch?v=s3WXUN3HnWw
Part two is here:youtube.com/watch?v=08Xex3n8Db8
