Uploaded May 2026 | Updated September 2026, 1 hour ago
This is the FP10000Q 10KW Amplifier that has been given me trouble. It appears to have a problem with the Idle Current / Bias Circuit. Sometimes you need to understand how something should work before you can figure out why it isn't working. Here is a slightly deep dive into the bias circuit with no complicated maths, just real life diagnostic work. If you ever wondered how this circuit works then give this video a go.
