JoshTheEngineer | GMSH: Unstructured Rectangular Mesh @JoshTheEngineer | Uploaded November 2017 | Updated October 2024, 1 hour ago.
In this video, we will create a rectangular, unstructured mesh that can be used in a CFD simulation.
If you're interested in how to use this mesh in a CFD simulation, stay tuned for some future videos.
===== GMSH AND SU2 =====
→ gmsh.info
→ su2code.github.io
===== RELEVANT VIDEOS =====
→ Gmsh: Stuctured (Transfinite) Rectangular Single Zone
goo.gl/1hpF9m
→ Gmsh: Structured (Transfinite) Rectangular Double Zone
goo.gl/RAebxS
===== NOTES =====
► For this video, I was using version 2.13.2
► The newest stable version is currently 3.0.6, and may behave slightly differently than seen in this video
===== REFERENCES =====
► Tutorial by Matthew MacLean
