In this video we pick up where we left off in the previous video on troubleshooting the EGO 650CFM Blower. We take time to show the Controller being tested and show example wiring diagram for the speed controller input. I shared the one failure of this Controller used in the Retrofit and that is also why this video has had a couple weeks delay as well. I really enjoy working with these small and cheap BLDC Controllers, they are easy to use and the few I have in other tools are still working great. I also have a video using a Low Voltage Cut Out if needed for such an application as this, it will keep the pack from discharging too far. Hope you find this video helpful and thanks for watching!
