Pipe Clamp / Bar Clamp Rack can be reconfigured and adjusted to hold various sizes of clamps. Saves space and time in the shop, because each size of clamp is visible and easily accessible... in other words, this clamp rack is "5S Compliant" in the woodworking shop.
See how Steve cuts dowels safely, sets up band saw cuts to speed up repetitive work, makes a template to mark out all the saw cuts, uses pre-cut spacers to keep the glue-up square and straight, and cuts French cleat notches quickly and easily.
Drawings are available as PDF files by clicking these links:
Bracket: highlandwoodworking.com/blog7/Clamp%20Bracket.pdf
Vertical "Standard":
highlandwoodworking.com/blog7/Clamp%20Standard%20Detail.pdf
Music...
"Welcome To The Show," "Feelin Good," Hackbeat,” & "Hustle" all written and performed by Kevin MacLeod (incompetech.com)
Licensed under Creative Commons: By Attribution 3.0
http://creativecommons.org/...
