You are watching Detailed DIY video about How to make World's Simplest Dual Battery Charger Circuit and 12V x 12V Power Supply at Home.

Hi viewers! in this video tutorial i am going to show you simple Dual Battery Charger and Power Supply DIY circuit by using some low cost materials lised below.

Circuit Diagram: drive.google.com/open?id=1C9P0gjM4zkAGcGl4gBYC5nUB6kS7UXu2

List Of Materials
1. 12V x 12V Transformer.
2. 8x Diode: 1N40075.
3. 2x Capacitors: 1000uF, 16V.
4. 2x Resistors: 1.2K Ohms.
5. Circuit Board.
6. Wood Base.
7. 2x 2" Nut Bolts.
and some basic tools.
For more useful DIY videos please subscribe our channel "IdeasTV".
Please give us your precious feedback below in comments also like this video and share with your friends :)
Thanks! have a nice day :)
