The priciple of engraving clear acrylic involves modifying the optical properties of the surface of the material to create largish bubbles. Most diode engraving I have seen creates just superficial surface damage akin to bead blasing ie very fine texture and rather grey, Yes, diode engraving affects the surface transparancy of the acrylic and it is this lack of trasnparancy that creates the apparent engraving effect. Acrylic does not absorb 450 nm light waves to any useful degree so there is insufficient energy transfer to cause heating. Without heat, clear acrylic will not be damaged. The usual way of getting heat into the surface involves adding a film of paint or other substances to act as an energy transfer meduim. The hope is that sufficient heat will conduct into the acrylic to damage it.. The efficiency of this heat transfer is very low, hence disruption to the acrylic surface is minimal and only few microns deep. I have conducted some interesting experiments withi this incedibly low power device and some of the results are remarkable. Even I am surprised and it certainly adds to my laser education .
Wood is an equally diificult material to engrave but it wiill mark if there is sufficient exposure time. This means VERY slow wood engraving. I have some interesting revalations of how the engraving speed can be dramatically improved by decoding the process by which material damagae happens.
