This model is designed to mount higher powered green laser to common low power laser level (ALTON MODEL 13202 PROFESSIONAL MULTI-BEAM LASER LEVEL KIT) for extended range. This build also used four 1/4-20 (preferably nylon: amzn.to/2JhDe71 ) to cinch the body to the level and two, to cinch the laser pointer to model. Note (on the top) serves dual purpose in that it also depresses the pointers fire button also.
Warning: Laser pointers are dangerous and should be used with care and with the appropriate protective eyewear such as these: amzn.to/3kRQ0ac for eye safety and also beware of other people and animals in the area of use which is at your own risk.
Download Model: designstore.diy3dtech.com/laser-pointer-to-level-adapter
**Print Settings**
Printer brand: Any
Printer: Any
Rafts: No
Supports: No
Resolution: 0.2 or 0.3mm
Infill: 20%
Filament color: Black (or you pick)
Filament material: diy3dtech.com/pla
