Uploaded September 2021 | Updated November 2026, 3 hours ago
This module combines many sections put together to create that iconic rumble you'll hear in my favorite techno tracks.
Here's the various sections in order, which you can assemble yourself to make a copy of this module LOLOLOL I realize literally nobody is crazy enough to do that :D
Proco Rat: electrosmash.com/proco-rat
PT2399 delay: sound-au.com/project26a.htm (Figure 3 is basically the delay I always use, but change R11 to maybe 4.7K to make the delays be able to runaway
FV-1 reverb: oh boy, I do NOT remember where I put the schematic for this... it's basically the reverb from the FV-1 datasheet with the 8th algorithm pre-selected, and the potentiometer for the "reverb amount" broken out to the front. I used larger input and output capacitors to let more bass through spinsemi.com/Products/datasheets/spn1001/FV-1.pdf (wet-only, there's NO dry signal going past the reverb)
Rene Schmitz's MS-20 VCF schmitzbits.de/ms20.html -- there's two of these, the FIRST wired as a high-pass, the SECOND wired as a low-pass. (thanks, Rene)
Ducking circuit from me (Juanito) instructables.com/Freestyle-High-Fidelity-Ducking-Circuit (the kick signal doesn't get mixed back in though, leave that part out)
Baxandall tone control sound-au.com/articles/eq.htm
Basic LED saturation circuit...... um... if you really want to build this, let me know and I'll draw you a schematic
And finally, a volume control.
