In this video I walk you through the installation and setup procedure of the Embrace Making Falcon 22W / 40W laser crosshairs. This module fits both models with and without the fume extraction nozzle. You can find it here:
► embracemaking.com/products/creality-falcon-2-22w-40w-laser-crosshairs
A laser crosshairs module is a tool designed to assist operators in aligning their workpieces efficiently and accurately. It projects a crosshair pattern onto the surface of the material, providing a visual guide for precise positioning. This feature dramatically simplifies the setup process, ensuring that your designs are flawlessly aligned before starting the engraving process.
Unfortunately the Creality Falcon 2 laser cutters and engravers do not come equipped with a laser crosshairs module making the alignment and positioning process quite cumbersome. Take the guesswork away with this upgrade!
DANGER: The laser crosshairs module is a 5mW Class IIIa red laser. Class IIIa lasers are continuous wave, intermediate power (1-5 mW) devices. Some examples of Class IIIa laser uses are laser pointers and laser scanners. Direct viewing of the Class IIIa laser beam could be hazardous to the eyes. Do not view the Class IIIa laser beam directly. Do not point a Class IIIa laser beam into another persons eyes.
Always wear your laser safety glasses when working with lasers! If you need a pair of laser safety glasses at a reasonable price, consider these here:
Laser Safety Glasses (Blue Diode / IR):
► embracemaking.com/products/laser-safety-glasses-blue-diode-ir
If you are a visual learner I would encourage you to watch the video to understand the install and calibration procedure. However, to supplement the video, there is a short written guide on the setup and calibration:
► embracemaking.com/blogs/resources/creality-falcon-22w-40w-laser-crosshairs-guide
Nominal offsets for normal planar (flat) position:
► 22W Module: X: -55mm Y: -43mm
► 40W Module: X: -60.5mm Y: -35mm
Nominal offsets for rotary position:
► 22W Module: X: -55mm Y: 0mm
► 40W Module: X: -60.5mm Y: 0mm
