In this 1 Min PCB Design Review, Tech Consultant Zach Peterson reviews a digitally isolated USB interface design submitted by community member Siddharth. The board impresses in several areas — Siddharth nearly nails parts parameterization, gets the USB differential pair impedance correct for a two-layer board, and produces a clean 3D layout. But a few details keep it from being a perfect submission.
Zach breaks down the issues worth fixing: a single inconsistent part number parameter on the CP2102 USB-to-UART chip, a dual power rail configuration (5V and 3.3V) that raises questions about self-powered USB device intent, untented vias that clash with solder-masked mounting holes, unnecessary length tuning on GPIO traces, and — in what may be a first for the channel — an entire bill of materials silkscreened onto the back side of the PCB. If you're designing USB interface boards or working on isolation circuits, this review is packed with practical DFM and schematic hygiene tips you can apply right away.
