BMW X3/X5/X6 Transfer Case Actuator Motor Repair @X8RLtdUK

Uploaded June 2019 | Updated September 2026, 2 weeks ago

Link to purchase item: x8r.co.uk/bmw/bmw-transfer-gear-repair.html?utm_source=youtube&utm_medium=social&utm_campaign=analytics

SYMPTOMS OF FAULT

Brake, ABS, and 4X4 lights all lit?
Clicking / juddering sound from transfer case “4X4 inactive” message.

THE FAULT

The gear within your transfer case actuator wears and causes the symptoms noted above.
Attached to the transfer case is an actuator motor, within in this there is a poor quality Nylon plastic gear, this is turned by a metal worm gear. Over time the Nylon wears down and strips and leads to the gear not turning; this results in the symptoms noted above. BMW do not supply this part as a spare, they will provide at vast cost a complete replacement motor, this however will fail again because of the Nylon gear.

THE SOLUTION

Fit our improved design actuator gear and restore your actuator motor.
Replace just the failing component the Nylon gear with our replacement gear made from a plastic / Carbon Fiber mixture; a far better quality part than OEM. This will repair the issue and save the cost of a new actuator motor that would just fail again. A high quality precision made improved material replacement part.

VEHICLES AFFECTED
X3 E83
2.0d 2003- 2006
2.0i 2003-2006
2.5i 2003-2006
3.0d 2003-2006
3.0i 2003-2006

X3 E83 LCI
1.8d 2009-2010
2.0d 2006-2010
2.0i 2006-2010
2.5si 2006-2010
3.0d 2006-2010

3.0i 2006-2010
3.0sd 2006-2010
3.0si 2006-2010

X5 E53
3.0d 2003-2006
3.0i 2003 (Oct onwards) -2006
4.4i 2003-2006
4.8is 2003 (Nov onwards) -2006

BMW X5 E70

3.0d 2006-2010
3.0sd 2007-2010
3.0si 2006-2010
3.5d 2008-2010
4.8i 2006-2010
X5 M 2008-2013

BMW X5 E70 LCI

35dX 2009-2013

BMW X6 E71

30dX 2007-2010
35dX 2005-2010
35iX 2007-2010
40dX some models
X6 M 2008-2014
X6 Hybrid 2009-2011
Associated part numbers:
27107566296
27107568267

ATC 400 ATC 500 ATC 700

27107566296GR, 7-10-7-566-296GR, 27 10 7 566 296GR, 27107566296GR, 27-10-7-566-296, 27 10 7 566 296 , 27107566296, BOSCH 013000850, 8473227771, 8472227771, 09-3509-010, 9 3509 010, 093509010, 2710 7528559-01.

YOU WILL RECEIVE

1X Carbon fibre reinforced plastic gear
