80/20: 10 Series Anchor Fastener (3395) @8020llc

Uploaded November 2024 | Updated September 2026, 1 week ago

To Purchase: bit.ly/3IOmiBb
Find in Catalog: bit.ly/428g7iZ
80/20 Website: bit.ly/3peM7n3

The standard anchor fastener assembly is comprised of a socket head cap screw, cam, and T-nut. It is one of the strongest internal fastening methods, offering a long-lasting connection. The anchor fastener provides infinite positioning along the mating profile's T-slot, allowing a large degree of adjustability. The anchor fastener provides 90 degree, flush, vibration resistant connections, especially convenient where space restrictions apply. This connection method requires a counterbore machining service on the mounting profile. Additional Information: Cams are available separately (without the socket head cap screw and T-nut) for instances where you want to create your own custom assembly.

80/20: 3 Color Andon Light with Audible (21003)

80/20: End Cap with Push-In Fastener (2015-PLAIN)

$80/20: End Caps Overview To Purchase: https://bit.ly/43L8qPZ Find in Catalog: https://bit.ly/428g7iZ 80/20 Website: https://bit.ly/3peM7n3 Hello and welcome to 80/20’s product highlight series. Today we’re going to take a look at end caps. These end caps are a perfect finishing touch for any project. Giving it a nice, clean, aesthetic look. They’re easy to install. They’re available in both fractional and metric, and compatible across a wide range of profile series. They’re also available in a wide variety of colors, and you can get them with or without lettering. Now these come in a couple different styles. One with a hole in the middle of it, so you can put it right over the end of the profile. Take a push pin, push it right into the middle of the profile, and hold it securely into place. Now you can also use a self tapping screw, which will bite into the aluminum for a secure connection. Now we have two other styles. One has a stem built into the back of it, that’s going to work just like your push in pin. Another one uses a set screw that when you tighten it down it will expand the stem on the back of the end cap, securing it to your bar. Now hopefully you found this segment on end caps helpful. For more information please visit 8020.net and be sure to subscribe to future 80/20 videos. And as always, make it a great day.$

80/20: 10 Series Gusseted Inside Corner Bracket (4132)

$80/20: Angle Plates Overview To Purchase: https://bit.ly/45Q1LpC Find in Catalog: https://bit.ly/428g7iZ 80/20 Website: https://bit.ly/3peM7n3 Hello, and welcome to 80/20s product highlight series. Today we are going to take a look at angle plates. The plates are perfect for joining two bars at an angle. 80/20s angle plates are not only easy to install, but also require no machining. They come in fractional, metric, and are available across a wide range of profile series. Here you can see a small sample of the angle plates that 80/20 offers. As you can see there is a wide variety of shapes, angles, and sizes, making it one of the more versatile fastening options 80/20 offers. Now one thing youll want to keep in mind when using angle plates is that you are going to need a bolt assembly to install it. Recommended bolt assemblies for all angle plates can be found in the 80/20 product catalog. Now when it comes to installing the angle plate, the first thing you are going to want to do is preload your hardware. Preloading not only makes it easier to install your angle plate, but also saves time during assembly. To save additional time, youre going to want to look for opportunities where you can substitute out a single T-nut, for a double T-nut. Now to get started, well take our angle plate that is partially preloaded and finish it up with one last bolt, and one last T-nut. Now the important thing with the T-nut, is to make sure the pilot hole is facing downward. Once we have that on there, well take our profile, and slide the angle plate on. Well get one half of it on there. Tighten it down. Well take our other profile, and slide it right onto the other half of the angle plate. Once we have that in there, well take our wrench, and tighten down the last two bolts. Once you have that tightened, you have a strong, secure connection. Now hopefully you have found this segment on the angle plates helpful. For more information, visit 8020.net and make sure to subscribe to future 80/20 videos. And as always, make it a great day.$

$80/20: Transition Plates Overview To Purchase: https://bit.ly/44DlebP Find in Catalog: https://bit.ly/428g7iZ 80/20 Website: https://bit.ly/3peM7n3 Hello, and welcome to 80/20s product highlight series. Today were going to take a look at the transition plates. These plates are perfect for joining two different series bars together. 80/20s transition plates are not only easy to install, but also require no machining. They come in fractional, metric, and are available across a wide range of profile series. Here you can see a small sample of the many transition plates 80/20 offers. As you can see, the plates come in a wide variety of shapes, and sizes, making it one of the more versatile fastening options 80/20 offers. Now one thing youll want to keep in mind when using the transition plate, is youre going to need bolt assemblies to install it. Recommended bolt assemblies for all transition plates can be found in the 80/20 product catalog. Now when it comes to installing the transition plate, the first thing youre going to want to do, is preload your hardware. Preloading not only makes it easier to install the transition plate, but also saves you time during assembly. To save additional time, youre going to want to look for opportunities where you can substitute out a single T-nut for a double T-nut. To get started, well take our transition plate with preloaded hardware in it, put one last bolt in it, and one last T-nut. Now the important thing when installing the T-nut, is to make sure the pilot hole is facing downwards. Get that on there. Well take our first bar, and slide the plate right on. Well get it lined up, take our wrench, and tighten it down. From there, well take our other bar, and slide it right on. Once we have the lined up, well take our other wrench, and tighten down those two bolts. Once tightened, we have a strong, secure connection. Now hopefully you found this segment on the transition plate helpful. For more information, visit 8020.net and make sure to subscribe to future 80/20 videos. And as always, make it a great day!$ $80/20: Profile Selection To Purchase: https://bit.ly/3M9p3zb Find in Catalog: https://bit.ly/428g7iZ 80/20 Website: https://bit.ly/3peM7n3 Hello and welcome to 80/20’s product highlight series. Today we’re going to take a look at the vast selection of profiles that 80/20 offers. 80/20’s profiles come in wide variety of shapes, sizes, and finishes to suit your project’s needs. Their available in fractional and metric measuring systems, and come standard with a clear anodize which prevents oxidation and corrosion. You have options available with up to 10 open Tslots. This means you can quickly and easily add profiles, parts, and accessories to your project. As well as make additions and changes later down the road. We have standard, light, and ultra light available to give you options when it comes to weight and strength. As well as a range of shapes to choose from. We have square, rectangle, angled, and radiused. The fractional series comes with Align-A-Grooves on it that makes it easy to line up bars for fast and accurate connections. There are also smooth option available for fractional series and all metric profile series are smooth for an aesthetic look that is also easy to clean. All 80/20 profiles come standard with a clear anodize and you can choose from a wide range of finishes and colors to match your project’s needs. Hopefully this video helps showcase some of the profiles 80/20 offers. For more information please visit 8020.net and be sure to subscribe to future 80/20 videos. And as always, make it a great day.$
