![#77-2 [GUIDE] Siglent SDS1204X-E bodeplot 📈 using FY6900 (Chapterized 🧾)](https://i.ytimg.com/vi/DqjhTfOy9NY/mqdefault.jpg "#77-2 [GUIDE] Siglent SDS1204X-E bodeplot 📈 using FY6900 (Chapterized 🧾)
Have you ever wanted to use the bode plot functionality of your Siglent oscilloscope, but did not have a Siglent AWG on hand? Watch this video to see how you can attach the FY6900 (and FY6800, FY6600) AWG to your Siglent SDS1xxx series scope.
You can find the source code here:
https://github.com/timkoers/espBode
You can buy the AWG here:
FeelElec FY6900 (20MHz to 60MHz): https://s.click.aliexpress.com/e/_d8uetg0
FeelElec FY6900 60MHz: https://www.banggood.com/FY6900-Dual-Channel-DDS-Function-Arbitrary-Waveform-Signal-Generator-Pulse-Signal-Source-Frequency-Counter-Fully-Numerical-Control-20MHZ30MHZ50MHZ60MHZ-p-1495502.html?zf=6303154
The ESP-01S can be found here:
https://s.click.aliexpress.com/e/_BfirlPh2
Chapters:
0:00 Intro
0:30 Discussing the DUT
2:00 Configuring the channel settings
2:45 Connecting the DUT
4:25 Frequency range setup
5:03 Starting the bodeplot
5:40 Setting up the FY6900
6:47 Bodeplot finished
7:54 Restarting the bodeplot
8:45 Frequency analysis using FFT
9:10 Configuring the FFT settings
11:05 Configuring the sweep settings
12:30 Starting the sweep
13:35 Setting the sweep to a wider range
13:45 Starting the sweep
14:00 Stabilizing the results
15:05 Another frequency sweep
18:00 Difference between bodeplot and FFT frequency analysis
18:30 Comparing bodeplot with FFT results for various devices
26:30 Outro
