Always wanted to build your own reflow oven? So did I, and I built one, controllable via WiFi.

In chapter two, we'll go over the firmware and the pcb (including components) of the reflow oven. Stay tuned!

Chapters:
00:00 Intro
00:11 Required components
04:41 Soldering the PCB
05:16 Opening up the oven
05:21 Installing the fuse
07:06 Wiring
08:49 Drilling the holes
09:35 Mounting the PCB
14:50 Installing temperature sensors
17:24 Powering it up
21:04 First test
24:22 Temperature probe fix
25:12 PID problems

Thanks for watching my video!

The repo can be found here: gitlab.com/timkoers/Yet-Another-Reflow-Oven
