Uploaded December 2017 | Updated September 2026, 3 weeks ago
We needed a power and heating source for the workshop, so a Diesel generator running as a CHP was the obvious choice.
The only problem is that they rather expensive to buy, so we decided to use what we have and source the stuff we don't have on the cheap and make it fit.
We already uploaded the making of the generator spacers, these are also in the playlist of this project which is here
youtube.com/playlist?list=PLJ5sckhk3niksLfKavlHqnvTfIbP4d3bY
Why we building it ...
Because we need more power and better heating, having only 3kW (13A/230V) single phase mains supply in the workshop is just not enough. It just gained some priority because it's getting colder, i also need to do some serious welding and if i push the Amps to far it just pops the fuse.
What we using ....
some time ago, It happened that a nice Diesel engine came along and about half a year later an affordable 22kVA 400V 3-phase alternator was found. The engine had no starter or alternator, and the generator head was not exactly a direct fit. After some more time we had most of the bits together and started to make something of it.
Final specifications and more details will follow along the series,
max rating should be around 20kVA at 50Hz/400V and about 25kVA at 60Hz/440V, three phase of course.
How we do it ....
Just follow along this series and you'll see
This episode includes sourcing of some major bits, making the adaptors for flywheel and housing, also assembling the main unit
The Diesel Generator project playlist is here
youtube.com/playlist?list=PLJ5sckhk3niksLfKavlHqnvTfIbP4d3bY
The playlist for the mystery project is here:
youtube.com/playlist?list=PLJ5sckhk3ninWKp5_LuLqT90IH8TIbbHf
(c) 2017
dynoguy.co.uk
