Uploaded September 2022 | Updated September 2026, 2 weeks ago
2023 Mercedes-Benz GLC SUV (X254) GLC 400e (381 Hp) PHEV 4MATIC 9G-TRONIC 2022 Specs
General information
Brand Mercedes-Benz
Model GLC
Generation GLC SUV (X254)
Modification (Engine) GLC 400e (381 Hp) PHEV 4MATIC 9G-TRONIC
Start of production June, 2022 year
Powertrain Architecture PHEV (Plug-in Hybrid Electric Vehicle)
Body type SUV
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 0.6-0.8 l/100 km 392.02 - 294.02 US mpg
470.8 - 353.1 UK mpg
166.67 - 125 km/l
CO2 emissions (WLTP) 14-19 g/km
Fuel Type petrol / electricity
Acceleration 0 - 100 km/h 5.6 sec
Acceleration 0 - 62 mph 5.6 sec
Acceleration 0 - 60 mph (Calculated by Auto-Data.net) 5.3 sec
Maximum speed 237 km/h 147.26 mph
Weight-to-power ratio 6 kg/Hp, 167.1 Hp/tonne
Weight-to-torque ratio 3.5 kg/Nm, 285.1 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 31.2 kWh
Battery technology Lithium-ion (Li-Ion)
Recuperation output 100 kW
All-electric range (WLTP) 104-120 km 64.62 - 74.56 mi
Average Energy consumption (WLTP) 24-26.8 kWh/100 km 38.62 - 43.13 kWh/100 mi
87 - 78 MPGe
4.2 - 3.7 km/kWh
2.6 - 2.3 mi/kWh
Max speed (electric) 140 km/h 86.99 mph
Electric motor 1
Electric motor power 136 Hp
Electric motor Torque 440 Nm 324.53 lb.-ft.
Engine location Electric motor, integrated into transmission
System power 381 Hp
System torque 650 Nm 479.42 lb.-ft.
Internal combustion engine specs
Power 252 Hp @ 5800 rpm.
Power per litre 126.1 Hp/l
Torque 400 Nm @ 2000-3200 rpm. 295.02 lb.-ft. @ 2000-3200 rpm.
Engine location Front, Longitudinal
Engine Model/Code M 254
Engine displacement 1999 cm3 121.99 cu. in.
Number of cylinders 4
Position of cylinders Inline
Compression ratio 10.5
Number of valves per cylinder 4
Fuel System Direct injection
Engine aspiration Twin-scroll turbo, Intercooler
Valvetrain DOHC
Oil viscosity Log in to see.Log in to see.
Engine oil specification
Engine systems Start & Stop System
Particulate filter
Space, Volume and weights
Kerb Weight 2280 kg 5026.54 lbs.
Max. weight 2840 kg 6261.13 lbs.
Max load 560 kg 1234.59 lbs.
Fuel tank capacity 49 l 12.94 US gal | 10.78 UK gal
Permitted trailer load with brakes (12%) 2000 kg 4409.25 lbs.
Permitted towbar download 100 kg 220.46 lbs.
Dimensions
Length 4716 mm 185.67 in.
Width 1890 mm 74.41 in.
Width including mirrors 2075 mm 81.69 in.
Height 1648 mm 64.88 in.
Wheelbase 2888 mm 113.7 in.
Front track 1627 mm 64.06 in.
Rear (Back) track 1640 mm 64.57 in.
Drag coefficient (Cd) 0.29
Minimum turning circle (turning diameter) 11 m 36.09 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode.
Drive wheel All wheel drive (4x4)
Number of Gears (automatic transmission) 9 G-TRONIC
Front suspension Independent multi-link
Rear suspension Pneumatic suspension, Independent multi-link
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
4-wheel steering (4WS, active rear steering)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size Front wheel tires: 235/55 R19
Rear wheel tires: 255/50 R19
Wheel rims size Front wheel rims: 8J x 19
Rear wheel rims: 9J x 18
