HAHA this one is someting I have never seen and I felt like I needed to share it. Looks like it will take me some time to clean hahaha
HAHA this one is someting I have never seen and I felt like I needed to share it. Looks like it will take me some time to clean hahaha


![AWD motor sync -3D printer - VzBoT
In this video, I show you a way to mechanically sync your motors together to avoid issues like vertical artifacts, extra load on motors, etc. Very simple and easy, but can be tricky if motor pulleys were first installed on the motor flat spot. Its a lot easier to install the pulleys on the round surface of the shaft for at least the front or rear motors (X + Y or X1 +Y1) before assembling the gantry and installing the belt. But if you didnt do that, this video is for you.
Stepper motor Activation macro (it also could be very useful to activate motors one at the time if you need, so you can use the gcode command too):
[gcode_macro enable_stepper]
gcode:
SET_STEPPER_ENABLE STEPPER=stepper_x ENABLE=1
SET_STEPPER_ENABLE STEPPER=stepper_x1 ENABLE=1
SET_STEPPER_ENABLE STEPPER=stepper_y ENABLE=1
SET_STEPPER_ENABLE STEPPER=stepper_y1 ENABLE=1
-Vz-HextrudORT: https://s.click.aliexpress.com/e/_DEZwqK3
-Goliath: https://s.click.aliexpress.com/e/_Dkk6WrN
-Fly Super 8: https://s.click.aliexpress.com/e/_A8mOXD
-Drivers https://s.click.aliexpress.com/e/_AFDBtp
- XY Motors: https://s.click.aliexpress.com/e/_9iN6y9
-Alu Water cooling blocks: https://s.click.aliexpress.com/e/_Dn5w5yn
-Fittings: https://s.click.aliexpress.com/e/_DEVthxH
-water cooling kit: https://s.click.aliexpress.com/e/_DncIzoB
-CPAP fan: https://s.click.aliexpress.com/e/_Dmk96Tz
-CPAP tube: https://s.click.aliexpress.com/e/_A9rUYd
-48V PSU: https://s.click.aliexpress.com/e/_Dcfga4L
(complete part list can be found on the BOM list on github link below)
-Eibos filament dryer: https://s.click.aliexpress.com/e/_Dc76jEb
Full VzBoT Printer project: (BOM, cad, stl): https://github.com/VzBot3D/
