Uploaded November 2024 | Updated November 2026, 2 hours ago
๐ *The full guide* : _https://core-electronics.com.au/guides/analogue-electronics/getting-started-with-voltage-dividers-a-practical-guide-for-makers/_
In this guide, we are going to learn about *Voltage dividers* in a practical and approachable sense for *makers*. We will be working through an example of *monitoring* a LiPo *battery voltage* with a *microcontroller*, and we will work through the Voltage divider diagram and *equation*, as well as simulating it in *Falstad* - a *math-free* way of calculating the needed *resistors*. We will also go through wiring up the divider, as well as some *helpful code* for our Pico microcontroller to read the input voltage of the divider.
๐ง๐จ๐งฐ Hardware featured in this guide:
*The Resistor Kit:*
_https://core-electronics.com.au/catalog/product/view/sku/COM-10969_
*Get a Pico Here:*
_https://core-electronics.com.au/raspberry-pi/pico.html#category_2118_
๐กโ If you have any questions about this content or want to share a project you're working on head over to our *maker forum:* _coreelec.io/forum_
0:00 Intro
0:27 What is a Voltage Divider?
1:53 Voltage Divider Diagram
2:59 Voltage Divider Equation
3:45 How Big Should the Resistor Be?
4:42 Simulating our Divider in Falstad
6:13 Calculating Needed Resistors Without Math
7:09 Standard Sized Resistors
8:35 Wiring-Up a Voltage Divider
10:05 Reading the Voltage with a Microcontroller
