6 Channel Stepper Motor Controller Board for M1S ODROID Hardkernel 2023-11-14 | The Stepper Motor Controller Board is mainly designed to control up to 6 stepper motors and can help to interface with peripherals through CAN bus and several GPIO pins. Most adaptable application with this board is 3D printer or CNC machine that usually uses 3~4 stepper motors. Different type of machines require different hardware functions, unsupported function in this board could be extended when small and lower power micro controller board is connected to CAN bus or USB port if required.On board DC step down power supply to provide 5V to ODROID-M1S6x step motor driver module support1x CAN-FD bus support1x ADC channel2x GPIO inputs1x MOSFET outputMore information : hardkernel.com
4 Channel Relay Board ODROID Hardkernel 2023-11-14 | 4 channel relay board will provide the ability to control high voltage and high current external devices through GPIO pins easily.Add-on board for ODROID-M1S only.4-channel relay control via GPIO pins.GPIO isolation using PC817 photocoupler to prevent interference from high voltage circuit.Single RS232 serial port.Board reset and power button pins (Optional)more information : hardkernel.com
Realtime NPU object detecting and tracking demo using MIPI camera on ODROID-M1 ODROID Hardkernel 2023-01-13 | This project uses the Yolov5s model to recognize the cell phone and the camera tracking it. The camera and motor control used ros2 and "odroid-wiringpi". Using ROS2 and NPU together is the first time in the odroid series.requirement:- ubuntu 20.04- Linux kernel 4.19- ros2-foxy- OpenCV (ver. 4.2 or higher)- Source of the demo: github.com/hardkernel/ros2_yolo_tracking- ODROID-M1: hardkernel.com/shop/odroid-m1-with-4gbyte-ram- MIPI camera: hardkernel.com/shop/m1-mipi-csi-camera-kit- Servos: SG90 x 2- pan tilt braket x 1manual:- refer to the demo's README.md(github.com/hardkernel/ros2_yolo_tracking/blob/master/README.md)
ODROID-HC4-P KIT ODROID Hardkernel 2022-11-16 | Consists of ODROID-HC4 board, a case made of a rigid PCB that can mount two 3.5-inch HDDs horizontally, cooling fan, cables and bolts. It's your own network storage device that you can enjoy creating yourself, and the HC4's Petitboot function and various latest OS support can be used without any changes. Please note that this product cannot mount any 2.5-inch storage device.ODROID-HC4-P KIT : hardkernel.com/shop/odroid-hc4-p-kitOLED+RTC for HC4-P : hardkernel.com/shop/oledrtc-for-hc4-pHC4-P Transformation KIT : hardkernel.com/shop/hc4-p-transformation-kit
ODROID-N2L Ubuntu Gnome Desktop 22.04 + Kernel 6.0 + Panfrost + Vulkan API (4GB model) ODROID Hardkernel 2022-11-08 | The ODROID-N2L is the low-cost variant of our most popular and powerful ARM SBC ODROID-N2+. We replaced the DDR4 RAM chips with a single LPDDR4 chip to minimize the PCB form factor and reduce power consumption. As a bonus, around 20% higher DRAM interface clock frequency is an obvious and important improvement. We could find 10% to 20% of increased system performance compared to the original N2+ in various benchmark test results.The GPU benchmark glmark2-es2 also showed about 10% of increased performance which is very similar to the improvement of the memory bandwidth (MBW) test.ODROID-N2L with 4GByte RAM : hardkernel.com/shop/odroid-n2l-with-4gbyte-ramODROID-N2L with 2GByte RAM : hardkernel.com/shop/odroid-n2l-with-2gbyte-ramSmaller and neater form factor: 69 x 56mm Small size allows for mounting inside a variety of small devicesSuitable for various standalone embedded system which don’t require Ethernet connectivitySuitable for building robots, drones, arcade consoles, human-machine-interface devices, and many other applicationsFaster and lower power consumption LPDDR4 RAMLightweightLow cost
ODROID-N2L Kiosk Frontend package + Chromium WebGL demo (2GB model) ODROID Hardkernel 2022-11-08 | The ODROID-N2L is the low-cost variant of our most popular and powerful ARM SBC ODROID-N2+. We replaced the DDR4 RAM chips with a single LPDDR4 chip to minimize the PCB form factor and reduce power consumption. As a bonus, around 20% higher DRAM interface clock frequency is an obvious and important improvement. We could find 10% to 20% of increased system performance compared to the original N2+ in various benchmark test results.The GPU benchmark glmark2-es2 also showed about 10% of increased performance which is very similar to the improvement of the memory bandwidth (MBW) test.ODROID-N2L with 4GByte RAM : hardkernel.com/shop/odroid-n2l-with-4gbyte-ramODROID-N2L with 2GByte RAM : hardkernel.com/shop/odroid-n2l-with-2gbyte-ramSmaller and neater form factor: 69 x 56mm Small size allows for mounting inside a variety of small devicesSuitable for various standalone embedded system which don’t require Ethernet connectivitySuitable for building robots, drones, arcade consoles, human-machine-interface devices, and many other applicationsFaster and lower power consumption LPDDR4 RAMLightweightLow cost
ODROID-H3+ Game Emulation Demo ODROID Hardkernel 2022-10-12 | The ODROID H-series is backIt is more powerful, offers higher performance and comes in two brand new models.ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Intel® Quad-Core Processor Jasper Lake N5105(H3+: N6005) has a base clock of 2GHz and a boost clock of 2.9GHz (H3+: 3.3GHz) with 1.5 MB L2 and 4 MB L3 cache by a 10 nm process.Up to 64GB Dual-channel Memory DDR4 PC4-23400 (2933MT/s)Two SO-DIMM slots, up to 32GB per slotPCIe 3.0 x 4 lanes for one M.2 NVMe storage2 x 2.5Gbit Ethernet ports2 x SATA 3.0 portsSSE4.2 accelerator (SMM, FPU, NX, MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AES)Intel UHD Graphics 24 EUs(H3+:32 EUs) Turbo 800MHz(H3+:900MHz)HDMI 2.0 and DP 1.2 multiple video outputsA configurable Unlimited Performance mode allowing the CPU to run in sustained turbo boost mode.
ODROID-H3 Case Type 1 ODROID Hardkernel 2022-10-12 | No Net card and space for 2 x 3.5” SATA drives.Buy Now : hardkernel.com/shop/odroid-h3-case-type-1ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Package contents:A. Cooling fan panelB. Side panelC. Top panelD. Side lock pieceE. Rear panelF. Front panelG. 1 x 92x92x25mm DC 5V Cooling FanH. 1 x 92mm Stainless Cooling Fan Grill I. 4 x 40mm (F) PCB SupportsJ. 4 x 10mm (M) PCB SupportsK. 4 x 6mm M3 Truss Head BoltsL. 8 x 10mm #6-32 Round Head ScrewsM. 4 x M5 PC Fan Screws
ODROID-H3 Case Type 2 ODROID Hardkernel 2022-10-12 | No Net card, no space for SATA storage.Buy Now: hardkernel.com/shop/odroid-h3-case-type-2ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Package contents:A. Top panelB. Back panelC. Front panelD. Bottom panelE. Left/Right panelF. 1 x 92mm Stainless Cooling Fan GrillG. 4 x 40mm (F) PCB SupportsH. 4 x 15mm (M) PCB Supports I. 4 x M5 NutsJ. 4 x Rubber Feet (Round / Clear)K. 8 x 6mm M3 Truss Head BoltsL. 4 x M5 Truss Head Bolts
ODROID-H3 Case Type 3 ODROID Hardkernel 2022-10-12 | No Net card and space for 2 x 2.5” SATA drives (max. 15mm thick).Buy Now : hardkernel.com/shop/odroid-h3-case-type-3ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Package contents:A. Top panelB. Rear panelC. Front panelD. Bottom panelE. Inner bracketF. 2 x 2.5” SATA HDD/SSD bracket G. Left/Right PanelH. 1 x 92mm Stainless Cooling Fan GrillI. 4 x 40mm (F) PCB SupportsJ. 4 x 15mm (M) PCB SupportsK. 4 x 40mm (M) PCB SupportsL. 16 x 6mm M3 Truss Head BoltsM. 4 x Rubber Feet (Round / Clear)N. 4 x M5 NutsO. 4 x M5 Truss Head Bolts
ODROID-H3 Case Type 4 ODROID Hardkernel 2022-10-12 | No Net card and space for 1 x 3.5” SATA drive or 2 x 2.5” SATA drives.Buy Now : hardkernel.com/shop/odroid-h3-case-type-4ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Package contents:A. Top panelB. Rear-top panelC. Rear panelD. Front panelE. Rear-back panelF. Bottom panelG. Front space fillerH. 2.5”/3.5” inner drive bracketI. Left/Right panelJ. 92mm stainless cooling fan grill for front/Rear-topK. 6 x 40mm (F) PCB SupportsL. 4 x 15mm (M) PCB SupportsM. 3 x 40mm (M) PCB SupportsN. 4 x Rubber Feet (Round / Clear)O.4 x 6mm #6-32 Round Head ScrewsP. 16 x 6mm Truss Head BoltsQ. 8 x M5 NutsR. 8 x M5 Truss Head Bolts
ODROID-H3 Case Type 5 ODROID Hardkernel 2022-10-12 | Space for Net card and 2 x 3.5” SATA drives.Buy Now : hardkernel.com/shop/odroid-h3-case-type-5ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Net Card : hardkernel.com/shop/h2-net-cardPackage contents:A. Cooling fan panelB. Side panelC. Top panelD. Side lock pieceE. Rear panelF. Front panelG. 1 x 92x92x25mm DC 5V Cooling FanH. 1 x 92mm Stainless Cooling Fan GrillI. 2 x 40mm (F/F) PCB SupportsJ. 2 x 40mm (M/F) PCB SupportsK. 2 x 40mm (F/F) PCB SupportsL. 4 x M5 PC Fan ScrewsM. 8 x 10mm #6-32 Round Head ScrewsN. 4 x 6mm M3 Truss Head Bolts
ODROID-H3 Case Type 6 ODROID Hardkernel 2022-10-12 | Space for Net card, no space for SATA storage.Buy Now : hardkernel.com/shop/odroid-h3-case-type-6 ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Net Card : hardkernel.com/shop/h2-net-cardPackage contents:A. Top panelB. Bottom panelC. Front panelD. Back panelE. Left/Right panelF. 1 x 92mm Stainless Cooling Fan GrillG. 4 x 40mm (F) PCB SupportsH. 4 x 20mm (M) PCB SupportsI. 2 x 16x9mm (M) Steel PCB SupportsJ. 4 x M5 Truss Head BoltsK. 2 x 16x9mm (M) Steel PCB SupportsL. 8 x 6mm M3 Truss Head BoltsM. 4 x Rubber Feet (Round / Clear)
ODROID-H3 Case Type 7 ODROID Hardkernel 2022-10-12 | Space for Net card and 2 x 2.5” SATA drives (max. 15mm thick).Buy Now : hardkernel.com/shop/odroid-h3-case-type-7ODROID-H3+ : hardkernel.com/shop/odroid-h3-plusODROID-H3 : hardkernel.com/shop/odroid-h3Net Card : hardkernel.com/shop/h2-net-cardPackage contents:A. Top panelB. Rear panelC. Front panelD. Bottom panelE. Inner bracketF. 2 x 2.5" SATA HDD/SSD bracketG. Left/Right PanelH. 1 x 92mm Stainless Cooling Fan GrillI. 4 x 40mm (F) PCB SupportsJ. 4 x 40mm (M) PCB SupportsK. 4 x 20mm (M) PCB SupportsL. 2 x 16x9mm (M) Steel PCB SupportsM. 16 x 6mm M3 Truss Head BoltsN. 4 x M5 Truss Head BoltsO. 4 x M5 NutsP. 4 x Rubber Feet (Round / Clear)
ODROID-M1 realtime NPU object detection demo ODROID Hardkernel 2022-04-21 | Realtime NPU object detection demo using MIPI camera (OV5647) on ODROID-M1- Linux kernel (4.19)- Ubuntu Gnome Desktop (Mali GPU Bifrost/Wayland)- 8~13 FPSObject detection of image file- Resolution of input source is limited to 640x640- Image processing by OpenCV- Supporting 80 objects using "YOLOv5s" modelBuy Now : hardkernel.comForum : forum.odroid.comSourceSupported objects using "YOLOv5s" model: github.com/hardkernel/rknpu2/blob/master/examples/rknn_cam_demo/model/coco_80_labels_list.txtSource of demos: github.com/hardkernel/rknpu2/tree/master/examples/rknn_cam_demo github.com/hardkernel/rknpu2/tree/master/examples/rknn_yolov5_demoSource of images: 00:51 2048x1536 flickr.com/photos/dcoetzee/3565592927 00:53 960x623 pixabay.com/ko/photos/%ec%95%a0%ec%99%84-%eb%8f%99%eb%ac%bc-%ea%b7%80%ec%97%ac%ec%9a%b4-%eb%8f%99%eb%ac%bc-3157961 00:55 1200x796 pxhere.com/en/photo/1420284 00:59 3500x2387 commons.wikimedia.org/wiki/File:Traffic_in_Brasilia_before_Brazil_%26_Chile_match_at_World_Cup_2010-06-28_1.jpg 01:02 5391x3598 commons.wikimedia.org/wiki/File:Office_rest_area_(Unsplash).jpg 01:05 960x720 pixabay.com/ko/photos/%EB%B0%94%EA%B5%AC%EB%8B%88-%EB%AA%A9%EC%9E%AC-%EA%B3%BC%EC%9D%BC-2175870 01:08 777x518 pixahive.com/photo/a-boy-playing-football-4 01:10 780x518 stockvault.net/photo/202058/baseball-player 01:14 780x673 stockvault.net/photo/204650/basketball-league 01:16 960x720 pixabay.com/ko/photos/%ec%99%80%ec%9d%b8-%ec%99%80%ec%9d%b8-%ec%9e%94-%eb%a7%88%ec%8b%9c%eb%8b%a4-%ec%9c%a0%eb%a6%ac-3832272
ODROID-M1 Dual-Display in Action! ODROID Hardkernel 2022-03-29 | The ODROID-M1 is a single board computer with a wide range of useful peripherals developed for use in a variety of industrial applications. To achieve this goal, we have developed various hardware accessories and device driver software over the past 10 months. In addition, RK3568B2, the core brain of ODROID-M1, is considered suitable for industrial use as the SoC manufacturer (Rockchip) guarantees supply for the next 15 years. Buy Now : hardkernel.comForum : forum.odroid.com
ODROID-GO Super ODROID Hardkernel 2021-01-22 | ODROID-GO Super hardware design is upgraded version of the OGA . The LCD size changed to 5 inches with a tempered cover glass and resolution changed to 854x480 pixels. New OGS has a 4000mAh battery. You can continuously play games for several hours depending on back light brightness.The OGS is pre-assembled in our factory instead of being a DIY assembled kit. hardkernel.com/shop/odroid-go-super-clear-whitehardkernel.com/shop/odroid-go-super-dim-grayforum.odroid.com/viewtopic.php?f=187&t=41283
ODROID-H2 Case Type 7 ODROID Hardkernel 2021-01-06 | This “Case Type 7” is designed for the user who needs high bandwidth network with mid-range storages. Basically, this is the fanless design and the heated air from a processor or the storages can be blow out through the 92mm cooling fan holes on top of this enclosure. But you also can install a 92x92mm standard PC cooling fan at the hole if the decent power for the fan is supplied.hardkernel.com/shop/odroid-h2-case-type-7
ODROID-H2 Case Type 6 ODROID Hardkernel 2021-01-06 | This “Case Type 6” is designed for the user who needs high performance network with a minimal or regular range storages. Basically, this is the fanless design and the heated air from a processor can be blow out through the 92mm cooling fan hole on top of this enclosure. But you also can install a 92x92mm standard PC cooling fan (optional) at the hole if the decent power for the fan is supplied.hardkernel.com/shop/odroid-h2-case-type-6
ODROID-H2 Case Type5 ODROID Hardkernel 2020-12-04 | We have a new case for ODROID-H2 series. It will be available from mid December. hardkernel.com/shop/odroid-h2plus
ODROID-N2+ Ubuntu 20.04 Gnome Desktop ODROID Hardkernel 2020-07-15 | High performance single board computer ODROID-N2+ 2.4Ghz ARM Cortex-A73 CPU. The main CPU is based on big.Little architecture which integrates a quad-core ARM Cortex-A73 CPU cluster and a dual core Cortex-A53 cluster with a new generation Mali-G52 GPU.ODROID-N2+ with 4GByte RAM : hardkernel.com/shop/odroid-n2-with-4gbyte-ram-2ODROID-N2+ with 2GByte RAM: hardkernel.com/shop/odroid-n2-with-2gbyte-ram-2Forum : forum.odroid.com/index.phpWiKi : wiki.odroid.com
Dolphin Emulator Test On ODROID N2+ Android Vulkan Driver ODROID Hardkernel 2020-07-15 | High performance single board computer ODROID-N2+ 2.4Ghz ARM Cortex-A73 CPU and Vulkan powered Mali G52 GPURunning Dolphin emulator on Android Pie full 64bit OS.It is still far from the perfection, but the average frame rate is about 22~25FPS and many GC games are quite playable. To enjoy the retro games with more fun, we’ve used an old tube TV with a CVBS analog video output on ODROID-N2+.ODROID-N2+ with 4GByte RAM : hardkernel.com/shop/odroid-n2-with-4gbyte-ram-2ODROID-N2+ with 2GByte RAM : hardkernel.com/shop/odroid-n2-with-2gbyte-ram-2Forum : forum.odroid.com/index.phpWiKi : wiki.odroid.com
How To Assemble ODROID-GO Advance Black Edition ODROID Hardkernel 2020-05-21 | ODROID-GO Advance Black Edition has a modern 64bit ARM low-power quad-core processor as well as wide-viewing-angle 3.5inch LCD.There are big improvements from this revision. - The power input port has changed to a USB Type-C connector.- A 802.11n SDIO WiFi module has been mounted on the PCB by default.- L2 and R2 shoulder buttons added.- A new shell case color is available.- The color of the PCB also changed to black from white.
How To Disassemble ODROIOD-GO Advance Black Edition ODROID Hardkernel 2020-05-21 | How To Assemble ODROIOD-GO Advance Black Edition : youtube.com/watch?v=V2_4llLPc_g&feature=youtu.be
ODROID-C4 Ubuntu minimal + Flutter UI framework for Home Automation ODROID Hardkernel 2020-04-23 | ODROID-C4 is a new generation single board computer that is more energy efficient and faster performing than ODROID-C2 which was introduced over four years ago as the world’s first affordable ARM 64bit computer.The main CPU of the ODROID-C4 is built with a quad-core Cortex-A55 cluster with a new generation Mali-G31 GPU. The A55 cores run at 2.0Ghz without thermal throttling using the stock heat sink allowing a robust and quiet computer. The CPU multi-core performance is around 40% faster, and the system DRAM performance is 50% faster than the ODROID-C2.ODROID-C4 : hardkernel.com/shop/odroid-c4Technical information at WiKi : wiki.odroid.com/odroid-c4/odroid-c4Forum : forum.odroid.com/index.php
ODROID-C4 Ubuntu 20.04 + Kernel 5.4 + Wayland + FireFox + WebGL ODROID Hardkernel 2020-04-23 | Ubuntu 20.04 Focal Fossa Minimal OS image for ODROID-C4 can be downloaded from bit.ly/2Sl1g2IODROID-C4 is a new generation single board computer that is more energy efficient and faster performing than ODROID-C2 which was introduced over four years ago as the world's first affordable ARM 64bit computer.The main CPU of the ODROID-C4 is built with a quad-core Cortex-A55 cluster with a new generation Mali-G31 GPU. The A55 cores run at 2.0Ghz without thermal throttling using the stock heat sink allowing a robust and quiet computer. The CPU multi-core performance is around 40% faster, and the system DRAM performance is 50% faster than the ODROID-C2.ODROID-C4 : hardkernel.com/shop/odroid-c4Technical information at WiKi : wiki.odroid.com/odroid-c4/odroid-c4Forum : forum.odroid.com/index.php
ODROID-C4 CoreELEC : 4K HDR +, Netflix 1080p, 8K-25FPS video playback with downscaling ODROID Hardkernel 2020-04-23 | ODROID-C4 is a new generation single board computer that is more energy efficient and faster performing than ODROID-C2 which was introduced over four years ago as the world's first affordable ARM 64bit computer.The main CPU of the ODROID-C4 is built with a quad-core Cortex-A55 cluster with a new generation Mali-G31 GPU. The A55 cores run at 2.0Ghz without thermal throttling using the stock heat sink allowing a robust and quiet computer. The CPU multi-core performance is around 40% faster, and the system DRAM performance is 50% faster than the ODROID-C2.ODROID-C4 : hardkernel.com/shop/odroid-c4Technical information at WiKi : wiki.odroid.com/odroid-c4/odroid-c4Forum : forum.odroid.com/index.php
ODROID-C4 Android 64bit and Vulkan GPU driver demo with PPSSPP “God of War” emulation ODROID Hardkernel 2020-04-23 | ODROID-C4 is a new generation single board computer that is more energy efficient and faster performing than ODROID-C2 which was introduced over four years ago as the world’s first affordable ARM 64bit computer.The main CPU of the ODROID-C4 is built with a quad-core Cortex-A55 cluster with a new generation Mali-G31 GPU. The A55 cores run at 2.0Ghz without thermal throttling using the stock heat sink allowing a robust and quiet computer. The CPU multi-core performance is around 40% faster, and the system DRAM performance is 50% faster than the ODROID-C2.ODROID-C4 : hardkernel.com/shop/odroid-c4Technical information at WiKi : wiki.odroid.com/odroid-c4/odroid-c4Forum : forum.odroid.com/index.php
ODROID-C4 Android IoT programming with Android Things compatible APIs ODROID Hardkernel 2020-04-23 | ODROID-C4 is a new generation single board computer that is more energy efficient and faster performing than ODROID-C2 which was introduced over four years ago as the world’s first affordable ARM 64bit computer.The main CPU of the ODROID-C4 is built with a quad-core Cortex-A55 cluster with a new generation Mali-G31 GPU. The A55 cores run at 2.0Ghz without thermal throttling using the stock heat sink allowing a robust and quiet computer. The CPU multi-core performance is around 40% faster, and the system DRAM performance is 50% faster than the ODROID-C2.ODROID-C4 : hardkernel.com/shop/odroid-c4Technical information at WiKi : wiki.odroid.com/odroid-c4/odroid-c4Forum : forum.odroid.com/index.php
How To Assemble ODROID-GO Advance Updated ODROID Hardkernel 2020-02-21 | ODROID-GO Advance is to play 16-bit or 32-bit retro games on a handheld device with more advanced features and capabilities than ODROID-GO. hardkernel.com/shop/odroid-go-advancewiki.odroid.com/odroid_go_advance/startforum.odroid.com/viewforum.php?f=186Processor: CPU: RockChip RK3326(Quad-Core ARM Cortex-A35 1.3GHz), GPU: Mali-G31 MP2Memory: 1GB (DDR3L 786Mhz, 32 Bits bus width)Storage: SPI Flash(16Mbytes Boot), Micro SD Card slot(UHS-1 Capable interface)Display: 3.5inch 320×480 TFT LCD (Wide viewing angle display, MIPI-DSI interface)Audio: Earphone stereo jack, Speaker 0.5Watt 8Ω monoBattery: Li-Polymer 3.7V/3000mAh, Up to 10 hours of continuous game playing timeDC Jack: 5V input: 2.5mm diameter DC plug: USB charging cable is included in the package.External I/O: USB 2.0 Host x 1, 10Pin IO port(I2C, GPIO, IRQ at 3.3Volt)Input Buttons: F1, F2, F3, F4, F5, F6, A, B, X, Y, Direction Pad, Left Shoulder, Right Shoulder, Analog JoystickPower consumption: game emulation: 200~300mA, Sleep mode: 5.3~5.8mA, Power off: 0.1mA At this moment, the trial BSP image supports the following systems.* atari2600* atari5200* atari7800* atarilynx* gamegear* gb* gba* gbc* mastersystem* megadrive* nes* pcengine* pcenginecd* psx* segacd* snes* psp
ODROID-GO Advance LCD Installation Guide ODROID Hardkernel 2020-02-19 | This video shows more detail guide to install the LCD. Full assembly guide : youtu.be/im46rlz0NwgODROID-GO Advance : hardkernel.com/shop/odroid-go-advanceODROID Forum : forum.odroid.com/viewforum.php?f=186ODROID WiKi : wiki.odroid.com/odroid_go_advance/start
ODROID-GO Advance Disassembly ODROID Hardkernel 2020-02-19 | This video is to help people disassemble ODROID-GO Advance. Please follow the instruction with special care. ODROID-GO Advance : hardkernel.com/shop/odroid-go-advanceODROID Forum : forum.odroid.com
Install Arduino IDE on ODROID SBCs ODROID Hardkernel 2020-02-12 | Generally, Arduino APIs are used for microcontrollers like Arduino-UNO, esp8266, etc. Now, install Arduino IDE and some dependencies on a Odroid itself and write code. The Odroid runs the code on its own once you upload the code.forum.odroid.com/viewtopic.php?f=180&t=37713Github:github.com/hhk7734/oduino
How To Assemble ODROID-GO Advance ODROID Hardkernel 2020-01-02 | ODROID-GO Advance is to play 16-bit or 32-bit retro games on a handheld device with more advanced features and capabilities than ODROID-GO. Available from end of January 2020.wiki.odroid.com/odroid_go_advance/startforum.odroid.com/viewtopic.php?f=187&t=37202hardkernel.com/shop/odroid-go-advanceProcessor: CPU: RockChip RK3326(Quad-Core ARM Cortex-A35 1.3GHz), GPU: Mali-G31 MP2Memory: 1GB (DDR3L 786Mhz, 32 Bits bus width)Storage: SPI Flash(16Mbytes Boot), Micro SD Card slot(UHS-1 Capable interface)Display: 3.5inch 320×480 TFT LCD (Wide viewing angle display, MIPI-DSI interface)Audio: Earphone stereo jack, Speaker 0.5Watt 8Ω monoBattery: Li-Polymer 3.7V/3000mAh, Up to 10 hours of continuous game playing timeDC Jack: 5V input: 2.5mm diameter DC plug: USB charging cable is included in the package.External I/O: USB 2.0 Host x 1, 10Pin IO port(I2C, GPIO, IRQ at 3.3Volt)Input Buttons: F1, F2, F3, F4, F5, F6, A, B, X, Y, Direction Pad, Left Shoulder, Right Shoulder, Analog JoystickPower consumption: game emulation: 200~300mA, Sleep mode: 5.3~5.8mA, Power off: 0.1mA At this moment, the trial BSP image supports the following systems.* atari2600* atari5200* atari7800* atarilynx* gamegear* gb* gba* gbc* mastersystem* megadrive* nes* pcengine* pcenginecd* psx* segacd* snes* psp
ODROID-GO Advance Game Test ODROID Hardkernel 2019-12-27 | ODROID-GO Advance is to play 16-bit or 32-bit retro games on a handheld device with more advanced features and capabilities than ODROID-GO. Available from end of January 2020.wiki.odroid.com/odroid_go_advance/startforum.odroid.com/viewtopic.php?f=187&t=37202hardkernel.com/shop/odroid-go-advanceProcessor: CPU: RockChip RK3326(Quad-Core ARM Cortex-A35 1.3GHz), GPU: Mali-G31 MP2Memory: 1GB (DDR3L 786Mhz, 32 Bits bus width)Storage: SPI Flash(16Mbytes Boot), Micro SD Card slot(UHS-1 Capable interface)Display: 3.5inch 320×480 TFT LCD (Wide viewing angle display, MIPI-DSI interface)Audio: Earphone stereo jack, Speaker 0.5Watt 8Ω monoBattery: Li-Polymer 3.7V/3000mAh, Up to 10 hours of continuous game playing timeDC Jack: 5V input: 2.5mm diameter DC plug: USB charging cable is included in the package.External I/O: USB 2.0 Host x 1, 10Pin IO port(I2C, GPIO, IRQ at 3.3Volt)Input Buttons: F1, F2, F3, F4, F5, F6, A, B, X, Y, Direction Pad, Left Shoulder, Right Shoulder, Analog JoystickPower consumption: game emulation: 200~300mA, Sleep mode: 5.3~5.8mA, Power off: 0.1mA At this moment, the trial BSP image supports the following systems.* atari2600* atari5200* atari7800* atarilynx* gamegear* gb* gba* gbc* mastersystem* megadrive* nes* pcengine* pcenginecd* psx* segacd* snes* psp
CoreELEC on ODROID-N2 ODROID Hardkernel 2019-08-21 | Collaboration with CoreELEC team have made the powerful media platform. CoreELEC is a new generation media center OS built for the best functionality with the great output picture quality. ODROID-N2 is a snappy AMLogic S922X device with great output picture quality.4K HDR10 and HLG capable platforms.Auto frame rate switching & dynamic range matching - 4K (HDR10) capable Hardware.The best passive heatsink design we’ve ever seen.Stable Gigabit Ethernet (1000M) is ready for reliable 7.1 HD audio - 4K HDR Bluray Rip home networked streaming.The only Linux Kodi Leia device that outputs correct 4K HDR Infoframe dataThe most powerful and affordable ARM based Linux board for 4K HDR video player, currently on the market.4:2:2 Chroma output is ready to play World’s best class passthrough feature including modern audio formats DTS:X and Dolby Atmos.forum.odroid.com/viewtopic.php?f=179&t=33956&start=100#p256944 Netflix plays smoothly at a Full-HD resolution thanks to the Widevine DRM implementation.forum.odroid.com/viewtopic.php?f=179&t=33956&start=50#p253628 3D-SBS and 3D-TAB are supported to play 3D videos Many different type of USB DVB receivers are working out of the box thank to the backported Linux media_build drivers. PSP & DreamCast emulation on EmuELEC Add-on (You can download a Kodi add-on for N2 board from this link)discourse.coreelec.org/t/sx05re-retro-emulation-kodi-addon-for-coreelec-released-for-testing/3203ODROID-N2 2GB : hardkernel.com/shop/odroid-n2-with-2gbyte-ramODROID-N2 4GB : hardkernel.com/shop/odroid-n2-with-4gbyte-ramCoreELEC : discourse.coreelec.org/c/single-board-computers/odroid-n2
ODROID-N2 Running WEBGL on Chromium with Wayland ODROID Hardkernel 2019-07-26 | Chromium package for ODROID-N2 is available now. The files can be downloaded and installable with these commands.$ sudo apt install git$ git clone --depth=1 gitlab.com/tobetter/buildroot_linux_amlogic_chromium.git -b aml64_buildroot_master chromium$ cd chromium$ sudo ./install.shLaunching ChromiumOnce installation is done, ODROID-N2 has the files in /usr/bin/chromium-browser and /etc/init.d/chromium to launch the Chromium. The default page to load with Chromium by default can be set in another file /etc/chromium.default. ODROID-N2 : hardkernel.com/shop/odroid-n2-with-4gbyte-ramWiki : wiki.odroid.com/odroid-n2/application_note/linux_drm_build#running_chromium_on_waylandForum : forum.odroid.com/viewforum.php?f=177
ODROID-N2 ODROID Hardkernel 2019-04-15 | ODROID-N2 is a new generation single board computer that is more powerful, more stable, and faster performing than N1.The main CPU of the N2 is based on big.Little architecture which integrates a quad-core ARM Cortex-A73 CPU cluster and a dual core Cortex-A53 cluster with a new generation Mali-G52 GPU.Thanks to the modern 12nm silicon technology, the A73 cores runs at 1.8Ghz without thermal throttling using the stock metal-housing heatsink allowing a robust and quiet computer.The CPU multi-core performance is around 20% faster and the GPU is 10% faster than the N1. The N2’s DDR4 RAM is running at 1320Mhz with 1.2volt low power consumption.The large metal housing heatsink is designed to optimize the CPU and RAM heat dissipation and minimize throttling. The CPU is placed on the bottom side of the PCB to establish great thermal characteristics.ODROID-N2 : hardkernel.com/shop/odroid-n2-with-4gbyte-ramODROID forum : forum.odroid.com/viewforum.php?f=175ODROID WiKi : wiki.odroid.com/odroid-n2/odroid-n2
VESA Mount Kit with ODROID-H2 Case Type 2 ODROID Hardkernel 2018-11-29 | This VESA kit helps to mount the ODROID-H2 enclosed with the “Case TYPE 1” to your LCD TV or LCD monitor. The “Case Type 1” and this kit can be put together with one of steel bracket using M5 bolts and nuts, it can be mounted with another bracket that is installed to VESA holes on your display device. The advantage to use this kit is that you can save lots of space on your desk.Supported VESA holes distance: 75mm ~ 100mmSuitable LCD TV or LCD monitor: 12” ~ 24”Bearing weight: 10KgVESA Mount Kit : hardkernel.com/shop/vesa-mount-kitODROID-H2 Case Type 2 : hardkernel.com/shop/odroid-h2-case-type-2
I2C 20x4 LCD Module for ODROID-H2 ODROID Hardkernel 2018-11-28 | This LCD displays 20 characters wide, 4 rows in white texts on blue background.It has a backlight, a contrast adjust potentiometer, and a simple I2C communication interface.You can connect it to ODROID-H2 with four jumper wires directly and you will like to monitor important real-time system information from Linux OS.SPECIFICATION I2C Address: 0x3F or 0x27 Number of Characters: 20 characters x 4 Lines Blue LED backlight with white font color Adjustable contrast Supply voltage: 3.3V Interface: I2C 400Khz Dot size: 0.55 x 0.55 mm Dot pitch: 0.60 x 0.60 mm Character size: 2.96 x 4.75 mm Character pitch: 3.55 x 5.35 mm Size: 98x60x22mmThis WiKi page explains how to use this LCD module with ODROID-H2.WiKi : wiki.odroid.com/odroid-h2/application_note/20x4lcd_i2c
LED Power Button for ODROID-H2 ODROID Hardkernel 2018-11-28 | Blue illuminated Power Button with pre-assembled jumper wires.Cable length : 260-290 mmThere is a small power switch on the ODROID-H2 board. But it is not easy to access the switch when you assemble(place?) the board in to a case. This beautifully illuminated power button is a good solution what you need!This button can be mounted on the official acrylic case Type-1, Type-2, Type-3 and Type-4.Note that the blue LED forward voltage must not exceed 3.5Volt.Red wire: LED positive (Anode) : pin-4 or pin-7 or pin-14 on 20 pin header of ODROID-H2Black wire: LED negative (Cathode) : GND(pin-1) on 20 pin header of ODROID-H2Blue wire : Switch-A : #PWR_BTN(pin-17) in 20 pin header of ODROID-H2Green wire : Switch-B: GND(pin-19) on 20 pin header of ODROID-H2hardkernel.com/shop/led-power-button
ODROID-H2 Case Type 1 ODROID Hardkernel 2018-11-28 | This “Case Type 1” is designed for the user who needs high bandwidth network with the high capacity storages for the high performance computing system. One 92mm standard PC cooling fan is applied to the side of the enclosure in order to blow out the heated air from the disk drives and the ODROID-H2.Supported storages:On-board eMMC 5.1 moduleOn-board M.2 NVMe (NGFF-2280)Up to 2 x 3.5” SATA HDD (At least 1 drive must be mounted in order to securely hold the enclosure structure)SATA Data & Power cables must be purchasedThe disk drive mounting screws (#6-32x10mm) are included in the package.The power and reset switches are accessible through the hole at the frontOptional LED Power Button (diameter: 16mm) can be installed at the frontSize : 118 (L) x 236 (W) x 132 (H) mmhardkernel.com/shop/odroid-h2-case-1
ODROID-H2 Case Type 2 ODROID Hardkernel 2018-11-26 | This “Case Type 2” is designed for the user who needs high performance network with a minimal or regular range storages. Basically, this is the fanless design and the heated air from a processor can be blow out through the 92mm cooling fan hole on top of this enclosure. But you also can install a 92x92mm standard PC cooling fan (optional) at the hole if the decent power for the fan is supplied.Supported storages:On-board eMMC 5.1 moduleOn-board M.2 NVMe (NGFF-2280)“SATA Data and Power Cable” must be purchasedThe disk drive mounting screws (M3x6mm) are included in the package.The power and reset switches are accessible through the hole at the frontOptional power on/off switch (diameter 16mm) can be installed at the front panel128 (L) x 132 (W) x 63 (H) mmhardkernel.com/shop/odroid-h2-case-type-2
ODROID-H2 Case Type 4 ODROID Hardkernel 2018-11-20 | This “Case Type 4” is designed for the user who needs high bandwidth network with mid-range storages. Basically, this is the fanless design and the heated air from a processor or the storages - especially a hard disk drive with a spinning motor - can be blow out through the two 92mm holes on top of the ODROID-H2 and the disk drives. But you also can install a 92x92mm standard PC cooling fan (optional) at a hole out of two on top of the ODROID-H2 if you supply the decent power for the fan.Supported storages:Due to the physical limitation of the design, two different size of storages cannot be installed and below combination of the storage drives are supported. On-board eMMC 5.1 moduleOn-board M.2 NVMe (NGFF-2280)Up to 1 x 3.5” SATA HDD or SSDUp to 2 x 2.5” SATA HDD or SSD (Max height : 15mm)“SATA Data and Power Cable” must be purchasedThe disk drive mounting screws (M3x6mm and #6-32x6mm) are included in the package.The power and reset switches are accessible through the hole at the frontOptional power on/off switch (diameter 16mm) can be installed at the fronthardkernel.com/shop/odroid-h2-case-4Optional accessory:SATA Data and Power Cablehardkernel.com/shop/sata-data-and-power-cableLED Power Buttonhardkernel.com/shop/led-power-button16Port I2C GPIO Boardhardkernel.com/shop/16port-i2c-gpio-board92x92x25mm DC 5V Cooling Fanhardkernel.com/shop/92x92x25mm-dc-cooling-fan-w-pwm-speed-sensor-tachoMechanical drawings:dn.odroid.com/temp/box/ODROID-H2_TYPE4.dxf
ODROID-H2 Case Type 3 ODROID Hardkernel 2018-11-20 | This “Case Type 3” is designed for the user who needs high bandwidth network with mid-range storages. Basically, this is the fanless design and the heated air from a processor or the storages can be blow out through the 92mm cooling fan holes on top of this enclosure. But you also can install a 92x92mm standard PC cooling fan (optional) at the hole if the decent power for the fan is supplied.Supported storages:On-board eMMC 5.1 moduleOn-board M.2 NVMe (NGFF-2280)Up to 2 x 2.5” SATA HDD or SSD (Max height : 15mm)“SATA Data and Power Cable” must be purchasedThe disk drive mounting screws (M3x6mm) are included in the package.The power and reset switches are accessible through the hole at the frontOptional power on/off switch (diameter 16mm) can be installed at the fronthardkernel.com/shop/odroid-h2-case-3Optional accessorySATA Data and Power Cablehardkernel.com/shop/sata-data-and-power-cableLED Power Buttonhardkernel.com/shop/led-power-button16Port I2C GPIO Boardhardkernel.com/shop/16port-i2c-gpio-board92x92x25mm DC 5V Cooling Fanhardkernel.com/shop/92x92x25mm-dc-cooling-fan-w-pwm-speed-sensor-tachoMechanical drawings:dn.odroid.com/temp/box/ODROID-H2_TYPE3.dxf
ODROID-H2 : Ubuntu 18.10 ODROID Hardkernel 2018-10-19 | ODROID-H2 is a Linux-friendly high-end SBC with a choice of Intel’s Gemini Lake 14nm quad-core 2.4Ghz processors plus HDMI 2.0 + DP 1.2 dual display support, M.2 NVMe 4-lane PCIe, 2 x SATA III, 2 x GbE, 2 x USB 3.0, 2 x USB 2.0 and native 3.3Volt I2C/UART ports. You can install up to 32GByte DDR4 memory into two SO-DIMM memory slots.More information : forum.odroid.com/viewtopic.php?f=29&t=32536hardkernel.com/shop/odroid-h2
ODROID-GO fMSX port : Multiplayer over WiFi direct ODROID Hardkernel 2018-10-05 | To celebrate ODROID’s 10th anniversary, we present the ODROID-GO Game Kit! It includes a special anniversary board with all the parts to put together your own game kit and see the workings behind such a device. It is not only a fun assembly project but also an educational tool to learn about all the hardware and software that goes into building such a device.ODROID-GO : hardkernel.com/main/products/prdt_info.php?g_code=G152875062626fMSX by Schuemi : github.com/Schuemi/fMSX-goODROID forum : forum.odroid.com/viewtopic.php?f=159&t=31927
ODROID-GO ODROID Hardkernel 2018-06-21 | ODROID-GO : hardkernel.com/main/products/prdt_info.php?g_code=G152875062626Assembly and learning WHY : wiki.odroid.com/odroid_go/go_assemblingMake a microSD card with your own game collections : wiki.odroid.com/odroid_go/emulator/make_sd_for_importing_romsTo celebrate ODROID’s 10th anniversary, we present the ODROID-GO Game Kit! It includes a special anniversary board with all the parts to put together your own game kit and see the workings behind such a device. It is not only a fun assembly project but also an educational tool to learn about all the hardware and software that goes into building such a device.Assembly and learning WHYHave fun building your own handheld game kit while learning about the internal functions of each part and its purpose. Learn how each button is attached to a PCB switch pad, what materials are used, and how to put it all together to create a button control pad to play games! Learn how to connect power, speakers and how to download and install an OS. Learn why certain pieces are made of particular materials and why you need certain connectors. Since the device is clear, all the internal components and all the lights are visible. PLAY GAMESOnce you have assembled the ODROID-GO, you can download and install games. Enjoy your gaming device (that you built)! CODING CAMPInstall Arduino and learn some basic coding. We will provide online guides to code some simple, yet cool, tasks. Then, add a weather station*, learn how to check the battery life, test the speaker, add an ultrasonic distance meter* and more. * Parts sold separately.
Beasts and Bumpkins on ODROID-XU4 ODROID Hardkernel 2017-12-13 | ODROID-XU4 : http://www.hardkernel.com/main/products/prdt_info.php?g_code=G143452239825GameStation Turbo with XBMC for XU4 : wiki.odroid.com/odroid-xu4/os_images/third_partyWindows Application Compatibility List running ExaGear 2.1 Desktop : oph.mdrjr.net/meveric/other/ExaGear
Diablo on ODROID-XU4 ODROID Hardkernel 2017-11-22 | ODROID-XU4 : http://www.hardkernel.com/main/products/prdt_info.php?g_code=G143452239825Installation Guide : magazine.odroid.com/wp-content/uploads/ODROID-Magazine-201706.pdf#page=18Windows Application Compatibility List : oph.mdrjr.net/meveric/other/ExaGear
