Uploaded August 2024 | Updated September 2026, 1 week ago

---

In this video, I reviewed UNI-T's UDP3305S programmable DC power supply. Product link: uni-trendus.com/products/udp3305s-4ch-performance-series-programmable-linear-dc-power-supply

This is a four channel linear power supply which offers two main independent output channels which can output 0-33V and 0-5.2A, these two channels can also operate in parallel or series modes. A third channel can output up to 6.2V with a maximum output current of 3.2A. The fourth channel is a 5V 2A USB port.

UNI-T UDP4303S Four Channel Programmable Linear Power Supply Review/Teardown: youtu.be/5zNuxZ64odU

00:00 Overview, specifications
03:13 Back panel
04:10 Powering on, user interface
06:34 Voltage setting accuracy, series mode
09:56 Current setting accuracy, parallel mode
12:15 Graphic display, list waveform output
14:57 Delayer functionality, on/off intervals
17:03 Load testing, super quiet fan
21:47 Voltage/current ripple noise measurement
23:54 Power on, current limit behavior
26:11 Utility, conclusions
