This video demonstrates how changing out the VCO Board while not fixing the problems gives clues about the possibility problems with other boards.

The Digital Control Board (DCB) now is also suspect. The DCB takes a BCD input from the band switch which it decodes and creates signals to steer the VCO for the proper band. There are two VCO's ad it appears that the higher frequency range VCO is operating albeit not on the proper range but does respond to the tuning of the Crystal Calibrator on the 10/15M Bands.

See hamradiogenius.blogspot.com for a more detailed discussion of this video.
