Uploaded April 2025 | Updated September 2026, 2 weeks ago

---

I had never heard of Lucas Deeco until working on these terminals. These two terminals are fascinating IP65 touch screen terminals for use in hostile environments. (Hostile to computers) Let's dig into what makes these tick and see if I can figure out why one of them is not working.

Part 1: This part!
Part 2: youtu.be/VXDWrebmlNg

-- Links

Manual:
archive.org/details/lucas-deeco-sealtouch-graphics-terminal-applications-manual

Photos and ROM dumps:
archive.org/details/lucas-deeco-seal-touch

Historical copy of Lucas Deeco's website:
web.archive.org/web/19980130115145/http://www.deeco.com

Patents:
patents.google.com/patent/US4812830A/en
patents.google.com/patent/US4893120A/en

Some linux support exists for Lucas Deeco monitors:
linuxdoc.org/HOWTO/Hardware-HOWTO/other.html

SCADA system integrators used these:
controlsystemsintegration.com/projects.htm
