Symmetrical versus Asymmetrical Bipolar Tesla coil power measurement. Part 1 @TheOldScientist

Uploaded March 2013 | Updated September 2026, 2 weeks ago

Website: vorticesdynamics.com

First part of the power analysis of power propagation of the Bipolar Tesla coil. The coil is symmetrical arranged between primary and secondary coil. Power measurement is done via the Agilent DSO-X 3014A, 4 channel. Current measurement via the Tektronix P6021 current probe, AC, 60 MHz, 15A. HV, 15KV DC, 40 KV AC , RF 50 MHz Voltage probes are the N2771B from Agilent.
